AMANA TOOL 43616 2 FLUTE PLUNGE 1/2" DIA. S.C
$82.28
In stock
SKU
33876
Plastic Solid Carbide Router Bits
Double
'O' Flute
|
D |
B |
d |
L |
Tool No. |
|
1/8 |
1/2 |
1/4 |
2 |
43600 |
|
3/16 |
5/8 |
1/4 |
2 |
43604 |
|
1/4 |
1 |
1/4 |
2-1/2 |
43608 |
|
1/2 |
1 |
1/2 |
3 |
43616 |
Max RPM Guide for Amana Tool® Router Bits
Do not exceed the maximum RPM shown for the particular tool
you are using. Max RPM for symmetrical tool only!
No exceda la maxima velocidad (RPM) indicada para cada
herramienta. Máximo RPM para la herramienta simétrica solamente!
|
Router Bit Dimensions |
Max RPM |
|
2" (Less than 50) |
28,000 |
|
2" - 2-3/8" (50-60mm) |
22,000 |
|
2-3/8" - 2-3/4" (60-70mm) |
19,000 |
|
2-3/4" - 3-1/4" (70-80mm) |
16,000 |
|
3-1/4" - 3-5/8" (80-90mm) |
15,000 |
|
3-5/8" < (90-100mm) |
13,000 |
Note: Please also refer to laser
etching on router bit shank for most updated RPM speed rating.
| Availability | In Stock |
|---|---|
| Manufacturer | AMANA TOOL |
| Manufacturer Sku | 43616 |
