AMANA TOOL 45500 MORTISING 1/2 DIA. 1/4 SHANK
$19.20
In stock
SKU
34191
Mortising Router Bits
2 Flute
For cutting
shallow mortises for hinges and locksets, use this bit. Its cutting geometry is
calculated to produce an exceptionally clean cut with crisp edges.
|
D |
B |
d |
L |
Tool No. |
|
1/2 |
3/4 |
1/4 |
2 |
45500 |
|
5/8 |
3/4 |
1/4 |
2 |
45502 |
|
3/4 |
3/4 |
1/4 |
2 |
45504 |
|
1-1/4 |
3/4 |
1/2 |
2-1/8 |
45505 |
Note: A proper mortising bit, as shown, should have
a large gullet between the two flutes. This allows greater chip clearance and
removal.
Max RPM Guide for
Amana Tool® Router Bits
Do not exceed the maximum RPM shown for the particular tool
you are using. Max RPM for symmetrical tool only!
No exceda la maxima velocidad (RPM) indicada para cada
herramienta. Máximo RPM para la herramienta simétrica solamente!
|
Router Bit Dimensions |
Max RPM |
|
2" (Less than 50) |
28,000 |
|
2" - 2-3/8" (50-60mm) |
22,000 |
|
2-3/8" - 2-3/4" (60-70mm) |
19,000 |
|
2-3/4" - 3-1/4" (70-80mm) |
16,000 |
|
3-1/4" - 3-5/8" (80-90mm) |
15,000 |
|
3-5/8" < (90-100mm) |
13,000 |
Note: Please also refer to laser
etching on router bit shank for most updated RPM speed rating.
| Availability | In Stock |
|---|---|
| Manufacturer | AMANA TOOL |
| Manufacturer Sku | 45500 |
