AMANA TOOL 45850 DOVETAIL 1/2 DIA W/UPPER BB
$37.88
In stock
SKU
34371
Dovetail Router Bits with Upper Ball Bearing Guide
2 Flute
This dovetail bit
has a shank-mounted ball-bearing guide for routing dovetail slots following a
template and pattern routing. The template must be mounted between the work
piece and the router. With a handheld router, the template must be on top of the
work. With a table-mounted router, the template must be underneath the work
piece.
Key Specifications
|
Angle (a°) |
D |
B
|
d |
L |
Tool No. |
|
14° |
1/2 |
1/2 |
1/4 |
2-1/4 |
45850* |
|
14° |
3/4 |
3/4 |
1/2 |
3 |
45852* |
For Both Hand Held
and Table Mounted Routers
NOTE: CAN BE USED
IN ALL HANDHELD AND TABLE-MOUNTED ROUTERS
Replacement Parts
for Tool No. 45850
Replacement
bearing - #47701
Replacement Collar
- #47724
Replacement Parts
for Tool No. 45852
Replacement
bearing - #47721
Replacement Collar
- #47739
* For Pattern
cutting or jigs
| Availability | In Stock |
|---|---|
| Manufacturer | AMANA TOOL |
| Manufacturer Sku | 45850 |
