AMANA TOOL 46300 SC SPIRAL FLUSH TRIM 1-1/4 2BB
$144.23
In stock
SKU
34560
UltraTrim™ Router Bits
Solid Carbide Spiral Trim - 2 Flute With
Double Ball Bearing Guides
For the ultimate, chip-free finish in laminate,
melamine, solid surface and fragile veneers, and for template work of all kinds.
The twin ball-bearing pilot enhances the stability of the tool. Available in
‘up-cut’ and ‘down-cut’ spirals.
|
D |
B |
d |
L |
'Up-cut' Tool No. |
'Down-cut' Tool No. |
|
1/2 |
1-1/4 |
1/2 |
3-3/4 |
46300 |
46400 |
|
1/2 |
2 |
1/2 |
4-3/4 |
46304 |
46404 |
Max RPM Guide for Amana Tool® Router Bits
Do not exceed the maximum RPM shown for the
particular tool you are using. Max RPM for symmetrical tool only!
No exceda la maxima velocidad (RPM) indicada para
cada herramienta. Máximo RPM para la herramienta simétrica solamente!
|
Router Bit Dimensions |
Max RPM |
|
2" (Less than 50) |
28,000 |
|
2" - 2-3/8" (50-60mm) |
22,000 |
|
2-3/8" - 2-3/4" (60-70mm) |
19,000 |
|
2-3/4" - 3-1/4" (70-80mm) |
16,000 |
|
3-1/4" - 3-5/8" (80-90mm) |
15,000 |
|
3-5/8" < (90-100mm) |
13,000 |
Note:
Please also refer to laser etching on router bit
shank for most updated RPM speed rating.
| Availability | In Stock |
|---|---|
| Manufacturer | AMANA TOOL |
| Manufacturer Sku | 46300 |
