AMANA TOOL 47128 FLUSH TRIM 3 FLUTE 1/2 SHANK
$44.78
In stock
SKU
34697
Extra Long Flush Trim Bits
With Ball Bearing Guide • 2 & 3
Flute
Use this bit for template or pattern work where the
workpiece is unusually thick. The two-flute configuration cuts fast and produces
a smooth finish. For a superior finish, use the three-flute version. Twin
bearings on selected tools provide better contact with reference edge and more
stability in the cut.
|
D |
B |
d |
L |
Flutes |
Tool No. |
|
1/2 |
1-1/2 |
1/2 |
3-7/8 |
2 |
47124 |
|
1/2 |
2 |
1/2 |
4-1/4 |
2 |
47126 |
|
1/2 |
1-1/2 |
1/2 |
4-1/16 |
2 |
**47124-2 |
|
1/2 |
2 |
1/2 |
4-3/8 |
2 |
**47126-2 |
|
1/2 |
1-1/2 |
1/2 |
3-7/8 |
3 |
47128 |
|
1/2 |
2 |
1/2 |
4-5/8 |
3 |
47131 |
|
1/2 |
1-1/2 |
1/2 |
4-1/16 |
3 |
**47128-2 |
** Denotes double ball bearing for added stability.
Standard replacement bearing (.500" dia.) use #47706.
Undersized bearing (.492" dia.), use #47715 - for use after
re-sharpening.
Max RPM Guide for Amana Tool® Router Bits
Do not exceed the
maximum RPM shown for the particular tool you are using. Max RPM for symmetrical
tool only!
No exceda la maxima velocidad (RPM) indicada para cada
herramienta. Máximo RPM para la herramienta simétrica solamente!
|
Router Bit Dimensions |
Max RPM |
|
2" (Less than 50) |
28,000 |
|
2" - 2-3/8" (50-60mm) |
22,000 |
|
2-3/8" - 2-3/4" (60-70mm) |
19,000 |
|
2-3/4" - 3-1/4" (70-80mm) |
16,000 |
|
3-1/4" - 3-5/8" (80-90mm) |
15,000 |
|
3-5/8" < (90-100mm) |
13,000 |
Note: Please also refer to
laser etching on router bit shank for most updated RPM speed rating.
| Availability | In Stock |
|---|---|
| Manufacturer | AMANA TOOL |
| Manufacturer Sku | 47128 |
