AMANA TOOL 47130 SUPER TRIM 3/4 DIA. UP SHEAR
$42.23
In stock
SKU
34700
Supertrim™ 3°
Shear Router Bit w/ Ball Bearing Guide
2 Flute
For exceptional
cutting speed, coupled with a super-finefinish, use these large-diameter flush
trim bits on a standard router.Available in either up-shear or down-shear.
Especially suitable for solidsurface material when used with optional #47709
Delrin® bearing. Furnished withsteel bearing #47714.
Key Specifications
|
D |
a° |
B |
d |
L |
Type |
Tool No.
|
|
3/4 |
3° |
1-1/2 |
1/2 |
3-7/8 |
Up |
47130 |
|
3/4 |
3° |
2 |
1/2 |
4-1/4 |
Up |
47134 |
|
3/4 |
3° |
1 |
1/2 |
3 |
Down |
47135 |
|
3/4 |
3° |
1-1/2 |
1/2 |
3-7/8 |
Down |
47136 |
|
3/4 |
3° |
2 |
1/2 |
4-1/4 |
Down |
47138 |
Note: Down-shear bits are notintended for table use.
Steel replacement
bearing #47714. Optional Delrin® bearing#47709
| Availability | In Stock |
|---|---|
| Manufacturer | AMANA TOOL |
| Manufacturer Sku | 47130 |
