AMANA TOOL 5005 TORX KEY T15
$7.61
In stock
SKU
35130
CNC Insert Straight Router Bits - Single & Double Flute
This group of router bits are not designed to plunge. Using
the so called ramping technique, such as shown on the right, the bit is eased in
and routes. Available in three different grades of carbide for various
applications.
|
ØD |
B |
Flutes |
Ød |
L |
Screw # |
T.C. Blade |
RPM |
Tool No. |
|
1/2" |
30 |
1 |
3/4" |
3-1/4" |
67117 |
AMA-30 |
14,000-18,000 |
RC-2154 |
|
5/8" |
30 |
1 |
3/4" |
3-3/8" |
67117 |
RCK-30 |
14,000-18,000 |
RC-2156 |
|
5/8" |
50 |
1 |
3/4" |
4-1/8" |
67117 |
RCK-50 |
14,000-18,000 |
RC-2158 |
|
5/8" |
30 |
2 |
3/4" |
3-3/8" |
67117 |
AMA-30 |
14,000-18,000 |
RC-2080 |
|
3/4" |
50 |
1 |
3/4" |
4-1/8" |
67117 |
RCK-50 |
14,000-18,000 |
RC-2162 |
|
3/4" |
30 |
2 |
3/4" |
3-3/8" |
67115 |
RCK-30 |
14,000-18,000 |
RC-2084 |
|
3/4" |
50 |
2 |
3/4" |
4-1/8" |
67115 |
RCK-30 |
14,000-18,000 |
*RC-2086 |
|
7/8" |
30 |
1 |
3/4" |
3-3/8" |
67117 |
RCK-30 |
14,000-18,000 |
RC-2164 |
|
7/8" |
50 |
1 |
3/4" |
4-1/8" |
67117 |
RCK-50 |
14,000-18,000 |
RC-2166 |
|
7/8" |
50 |
2 |
3/4" |
4-1/8" |
67115 |
RCK-30 |
14,000-18,000 |
*RC-2090 |
Note: All above two flute cutters have two cutting edges
per knife.
*50mm cutting edge is achieved using two 30mm staggered
knives.
Replacement Parts
|
Description |
T.C. Blade |
T.C. Blade |
T.C. Blade |
Torx® Screw |
Torx® Key |
|
|
Tool No. |
AMA-30 |
RCK-30 |
RCK-50 |
67117 |
67115 |
5005 |
|
Size |
30x9x1.5 |
30x12x1.5 |
50x12x1.5 |
M3.5x4.8 Ø1/2"-Ø5/8" |
M4x5.6 Ø3/4"-Ø7/8" |
T15 |
| Availability | In Stock |
|---|---|
| Manufacturer | AMANA TOOL |
| Manufacturer Sku | 5005 |
