AMANA TOOL 51201 DOUBLE PANEL PILOT FLUSH TRIM
$19.88
Out of stock
SKU
35163
Double End Panel Pilot Solid Carbide Bits
Single Flute
Unique double ended panel pilot router bits provide 2
cutting sides in one tool. When the router bit dulls, just flip it over!
Here's the ideal laminate trimming router bit for high
volume production. Solid carbide and integral pilot (no bearing to maintain)
extend life of router bit, slim configuration reduces vibration. Suitable for
routers and trimmers.
|
ØD |
B |
Ød |
L |
Type of Cut |
Tool No. |
|
1/4 |
1/4 |
1/4 |
2 |
Flush |
51201 |
|
1/4 |
1/4 |
1/4 |
2 |
7° Bevel |
51203 |
Max RPM Guide for Amana Tool® Router Bits
Do not exceed the maximum RPM shown for the particular tool
you are using.
Max RPM for symmetrical tool only!
No exceda la maxima velocidad (RPM) indicada para cada
herramienta.
Máximo RPM para la herramienta simétrica solamente!
|
Router Bit Dimensions |
Max RPM |
|
2" (Less than 50) |
28,000 |
|
2" - 2-3/8" (50-60mm) |
22,000 |
|
2-3/8" - 2-3/4" (60-70mm) |
19,000 |
|
2-3/4" - 3-1/4" (70-80mm) |
16,000 |
|
3-1/4" - 3-5/8" (80-90mm) |
15,000 |
|
3-5/8" < (90-100mm) |
13,000 |
Note: Please also refer to
laser etching on router bit shank for most updated RPM speed rating.
| Availability | Out of Stock |
|---|---|
| Manufacturer | AMANA TOOL |
| Manufacturer Sku | 51201 |
