AMANA TOOL 51324 STAGGER TOOTH 1/2 DIA 1/2 SHK
$45.11
In stock
SKU
35198
Opposite-Shear
Staggered Tooth Router Bits
2 Flute
A stagger-tooth
bit has two cutting edges, each only half the flute length, located 180° apart,
one high, one low. The result is a tool that combines the speed and chip
clearance of a one-flute bit with the strength and balance of a two-flute bit.
This “opposite-shear” configuration features a down-shear edge and an up-shear
edge. On a through-cut, it shears down on both surfaces at the same time. It is
excellent for working double-sided melamine, plywood, laminates, and veneers, as
well as solid-surface materials.
Key Specifications
|
D |
B |
d |
L |
Tool No. |
|
1/2 |
1-1/8 |
1/2 |
3-1/8 |
51318 |
|
1/2 |
1-1/2 |
1/2 |
3-1/8 |
51320 |
|
1/2 |
2 |
1/2 |
4-1/8 |
51324 |
Max RPM Guide for Amana Tool® Router Bits
Do not exceed the
maximum RPM shown for the particular tool you are using. Max RPM for symmetrical
tool only!
No exceda la maxima velocidad (RPM) indicada para cada
herramienta. Máximo RPM para la herramienta simétrica solamente!
|
Router Bit Dimensions |
Max RPM |
|
2" (Less than 50) |
28,000 |
|
2" - 2-3/8" (50-60mm) |
22,000 |
|
2-3/8" - 2-3/4" (60-70mm) |
19,000 |
|
2-3/4" - 3-1/4" (70-80mm) |
16,000 |
|
3-1/4" - 3-5/8" (80-90mm) |
15,000 |
|
3-5/8" < (90-100mm) |
13,000 |
Note: Please also refer to laser
etching on router bit shank for most updated RPM speed rating.
| Availability | In Stock |
|---|---|
| Manufacturer | AMANA TOOL |
| Manufacturer Sku | 51324 |
