AMANA TOOL 51502 1/4"Dx1/4"SHK SPIRAL O ALUMINU
$42.75
Out of stock
SKU
35225
Aluminum Solid Carbide Router Bits
Spiral 'O' - Single Flute, Up-cut
The aluminum cutting spiral router bit was designed to eject chips
UP. The most popular design. Fits most CNC machines .
Router Bit Application
Aluminum, Brass, Copper and Non-ferrous Metals
·
Right Hand Helix
·
Right Hand Cut
Benefits of "Mirror Finish" Polished Flute:
•
Razor sharp cutting edge for effortless chip removal
•
Helps prevent chip re-welding or adhering to the tool
•
Extended Tool Life
•
Exceptional Cut Quality
|
D |
B |
d |
L |
'Up-Cut' Tool No. |
|
1/16 |
1/4 |
1/8 |
1-1/2 |
51470* |
|
3/32 |
1/4 |
1/8 |
2 |
51472* |
|
1/8 |
1/4 |
1/4 |
2 |
51474 |
|
1/8 |
5/16 |
1/8 |
1-1/2 |
51406 |
|
1/8 |
1/2 |
1/4 |
2 |
51454 |
|
3/16 |
3/8 |
1/4 |
2 |
51477 |
|
3/16 |
1/2 |
1/4 |
2 |
51408 |
|
3/16 |
5/8 |
1/4 |
2 |
51478 |
|
3/16 |
7/8 |
1/4 |
2-1/2 |
51456 |
|
1/4 |
3/8 |
1/4 |
2 |
51479 |
|
1/4 |
5/8 |
1/4 |
2 |
51402 |
|
1/4 |
3/4 |
1/4 |
2-1/2 |
51480 |
|
1/4 |
7/8 |
1/4 |
2-1/2 |
51458 |
|
1/4 |
1-1/4 |
1/4 |
3 |
51481 |
|
D |
B |
d |
L |
'Down-Cut' Tool No. |
|
1/8 |
5/16 |
1/8 |
1-1/2 |
51506 |
|
3/16 |
1/2 |
1/4 |
2 |
51508 |
|
1/4 |
5/8 |
1/4 |
2 |
51502 |
*High finish (not mirror finish due to small diameter)
Please note: For aluminum cutting please lubricate. Maximum RPM = 35,000
Max RPM Guide for Amana Tool® Router Bits
Do not exceed the maximum
RPM shown for the particular tool you are using. Max RPM for symmetrical tool
only!
No exceda la maxima velocidad (RPM) indicada para cada herramienta.
Máximo RPM para la herramienta simétrica solamente!
|
Router Bit Dimensions |
Max RPM |
|
2" (Less than 50) |
28,000 |
|
2" - 2-3/8" (50-60mm) |
22,000 |
|
2-3/8" - 2-3/4" (60-70mm) |
19,000 |
|
2-3/4" - 3-1/4" (70-80mm) |
16,000 |
|
3-1/4" - 3-5/8" (80-90mm) |
15,000 |
|
3-5/8" < (90-100mm) |
13,000 |
Note:
Please also refer to laser etching on router bit shank for most updated RPM
speed rating.
| Availability | In Stock |
|---|---|
| Manufacturer | AMANA TOOL |
| Manufacturer Sku | 51502 |
