AMANA TOOL 51582 CONVEX EDGING BIT 1/2 SHANK
$44.85
In stock
SKU
35269
Convex Edging Router Bits
2 Flute
Cuts a shallow arc—the fingernail shape—rather than a full
180-degree roundover. Like the bullnose radius bit, it has short flats above and
below the cutter arc, which produce fillets on stock thicker than 7/8". Must be
used with an edge guide on handheld routers or the fence on a router table.
|
D |
R |
B |
B1 |
d |
L |
Tool No. |
|
13/16 |
23/32 |
1-1/4 |
27/32 |
1/4 |
2-1/2 |
51580 |
|
13/16 |
23/32 |
1-1/4 |
27/32 |
1/2 |
2-3/4 |
51582 |
|
29/32 |
23/32 |
1-1/4 |
27/32 |
1/2 |
2-3/4 |
51586* |
Cuts a shallow radius ('thumbnail' shape) on board edges.
*Replacement bearing 47712 (2)
Max RPM Guide for Amana Tool® Router Bits
Do not exceed the maximum RPM shown for the particular tool
you are using.
Max RPM for symmetrical tool only!
No exceda la maxima velocidad (RPM) indicada para cada
herramienta.
Máximo RPM para la herramienta simétrica solamente!
|
Router Bit Dimensions |
Max RPM |
|
2" (Less than 50) |
28,000 |
|
2" - 2-3/8" (50-60mm) |
22,000 |
|
2-3/8" - 2-3/4" (60-70mm) |
19,000 |
|
2-3/4" - 3-1/4" (70-80mm) |
16,000 |
|
3-1/4" - 3-5/8" (80-90mm) |
15,000 |
|
3-5/8" < (90-100mm) |
13,000 |
Note: Please also refer to
laser etching on router bit shank for most updated RPM speed rating.
| Availability | In Stock |
|---|---|
| Manufacturer | AMANA TOOL |
| Manufacturer Sku | 51582 |
