AMANA TOOL 53204 3 WING SLOTT CUTTER 3/32 KERF
$21.23
In stock
SKU
35300
2&3 Wing Slotting Cutters
Two-and three-wing
slotting cutters are available individually. Use a two-wing cutter for faster
feed rates, three-wing cutters for better cut finish.
Key Specifications
|
B Kerf
|
D |
d1 Bore
|
2 Wing Tool No. |
3 Wing Tool No. |
|
1/16 |
1-7/8 |
5/16 |
53100 |
53200 |
|
5/64 |
1-7/8 |
5/16 |
53102 |
53202 |
|
3/32 |
1-7/8 |
5/16 |
53104 |
53204 |
|
1/8 |
1-7/8 |
5/16 |
53106 |
53206 |
|
5/32 |
1-7/8 |
5/16 |
53107* |
53207* |
|
3/16 |
1-7/8 |
5/16 |
53108 |
53208 |
|
7/32 |
1-7/8 |
5/16 |
53109 |
53209 |
|
1/4 |
1-7/8 |
5/16 |
53110 |
53210 |
*5/32" size also
used for ''biscuit-joint'' cutting.
* A full 3/4" cut
can be achieved using one additional#53107 cutter (available separately).
Max RPM Guide for Amana Tool® Router Bits
Do not exceed the maximum RPM shown for the particular tool
you are using.
Max RPM for symmetrical tool only!
No exceda la maxima velocidad (RPM) indicada para cada
herramienta.
Máximo RPM para la herramienta simétrica solamente!
|
Router Bit Dimensions |
Max RPM |
|
2" (Less than 50) |
28,000 |
|
2" - 2-3/8" (50-60mm) |
22,000 |
|
2-3/8" - 2-3/4" (60-70mm) |
19,000 |
|
2-3/4" - 3-1/4" (70-80mm) |
16,000 |
|
3-1/4" - 3-5/8" (80-90mm) |
15,000 |
|
3-5/8" < (90-100mm) |
13,000 |
Note: Please also refer to laser etching on router bit
shank for most updated RPM speed rating.
| Availability | In Stock |
|---|---|
| Manufacturer | AMANA TOOL |
| Manufacturer Sku | 53204 |
