AMANA TOOL 54110 OGEE FILLET 1-3/8 DIA. 1/4 SHK
$69.68
In stock
SKU
35380
Ogee Fillet Router
Bits
2 Flute
with Ball Bearing Guide
The ogee pattern
has a step at the end of the concave portion of the curve. Using the optional
3/8" bearing produces with a fillet at the convex end of the curve. Use in a
handheld or table-mounted router.
Key Specifications
|
D |
R1 |
R2 |
B |
d
|
L |
Tool No. |
|
|
1-3/8 |
5/32 |
5/32 |
1/2 |
1/4 |
2-1/16 |
54110 |
|
|
1-3/8 |
5/32 |
5/32 |
1/2 |
1/2 |
2-1/2 |
54112 |
|
|
1-5/8 |
1/4 |
1/4 |
3/4 |
1/2 |
2-5/8 |
54114 |
|
|
18! |
2-1/4 |
3/8 |
3/8 |
15/16 |
1/2 |
2-7/8 |
54127 |
A- Standard 1/2"
Bearing #47706 (included)
B- Optional 3/8"
Bearing #47702 (order separately)
Warning: Maximum RPM 18!
= 18,000
| Availability | In Stock |
|---|---|
| Manufacturer | AMANA TOOL |
| Manufacturer Sku | 54110 |
