AMANA TOOL 54141 CLASSICAL MOULDING 1/2 SHANK
$82.28
In stock
SKU
35418
Classical Molding
Router Bits
2 Flute
with Ball Bearing Guide
A cove flanked by
step fillets, a classical project used in period moldings, is produced by this
tool. Use in either handheld or table-mounted router.
Key Specifications
|
D
|
R |
B |
d |
L |
Tool No. |
|
1-1/8 |
5/32 |
1/2 |
1/4 |
2 |
54136 |
|
1-3/8 |
7/32 |
11/16 |
1/4 |
2-3/16 |
54138 |
|
1-1/8 |
5/32 |
1/2 |
1/2 |
2-3/8 |
54140 |
|
1-3/8 |
7/32 |
11/16 |
1/2 |
2-9/16 |
54142 |
|
1-1/2 |
1/4 |
3/4 |
1/2 |
2-3/4 |
54141
|
A- Standard 1/2"
Bearing #47706 (Included)
B- Optional 3/8"
Bearing #47702 (Order Separately)
Max RPM Guide for Amana Tool® Router Bits
Do not exceed the maximum RPM shown for the particular tool
you are using. Max RPM for symmetrical tool only!
No exceda la maxima velocidad (RPM) indicada para cada
herramienta. Máximo RPM para la herramienta simétrica solamente!
|
Router Bit Dimensions |
Max RPM |
|
2" (Less than 50) |
28,000 |
|
2" - 2-3/8" (50-60mm) |
22,000 |
|
2-3/8" - 2-3/4" (60-70mm) |
19,000 |
|
2-3/4" - 3-1/4" (70-80mm) |
16,000 |
|
3-1/4" - 3-5/8" (80-90mm) |
15,000 |
|
3-5/8" < (90-100mm) |
13,000 |
Note: Please also refer to
laser etching on router bit shank for most updated RPM speed rating.
| Availability | In Stock |
|---|---|
| Manufacturer | AMANA TOOL |
| Manufacturer Sku | 54141 |
