AMANA TOOL 54188 EDGE FORMING BIT 1/2 SHANK
$126.49
In stock
SKU
35452
Matched Bead Router Bits
2 Flute with Ball Bearing Guide
This dual purpose bit produces both moldings and joints.
Use in place of matched flute-and-bead bit sets to mill the edges of strips used
in various stave constructions like planters, canoes and hot tubs. Switch from
fluting to beading by raising or lowering the bit. Pilot bearing allows use for
template-guided cuts. Recommended for router table use; smaller sizes can be
used with an edge-guide equipped portable router.
|
|
øD |
R |
B |
ød |
L |
Tool No. |
|
|
1-1/4 |
3/16 |
1 |
1/2 |
2-7/8 |
54186? |
|
18! |
2 |
1/4 |
1-1/4 |
1/2 |
3 |
54188? |
Replacement bearing for #54184 and #54186 use #47706.
Replacement bearing for #54188 use #47716.
Warning: Maximum RPM
18!
= 18,000
?USE
IN A TABLE MOUNTED ROUTER. NOT FOR USE IN A HAND HELD ROUTER!
Max RPM Guide for Amana Tool® Router Bits
Do not exceed the maximum RPM shown for the particular tool
you are using. Max RPM for symmetrical tool only!
No exceda la maxima velocidad (RPM) indicada para cada
herramienta. Máximo RPM para la herramienta simétrica solamente!
|
Router Bit Dimensions |
Max RPM |
|
2" (Less than 50) |
28,000 |
|
2" - 2-3/8" (50-60mm) |
22,000 |
|
2-3/8" - 2-3/4" (60-70mm) |
19,000 |
|
2-3/4" - 3-1/4" (70-80mm) |
16,000 |
|
3-1/4" - 3-5/8" (80-90mm) |
15,000 |
|
3-5/8" < (90-100mm) |
13,000 |
Note: Please also refer to laser etching on router bit
shank for most updated RPM speed rating.
| Availability | In Stock |
|---|---|
| Manufacturer | AMANA TOOL |
| Manufacturer Sku | 54188 |
