AMANA TOOL 54297 BASE MOLDING 1/2 SHANK
$70.01
In stock
SKU
35518
Base Moulding Ogee Edge Detail
2 Flute
|
D |
R |
R1 |
B |
B1 |
d |
L |
Tool No. |
|
1-7/16 |
5/16 |
3/8 |
19/32 |
3/8 |
1/2 |
2 |
54297 |
Base Moulding Ogee Edge Detail with Ball Bearing
2 Flute
|
D |
R |
R1 |
B |
d |
L |
Tool No. |
|
1-53/64 |
19/64 |
13/32 |
3/8 |
1/2 |
1-19/32 |
54299 |
Replacement bearing #47706
Replacement screw #67014
Max RPM Guide for Amana Tool® Router Bits
Do not exceed the maximum RPM shown for the particular tool
you are using.
Max RPM for symmetrical tool only!
No exceda la maxima velocidad (RPM) indicada para cada
herramienta.
Máximo RPM para la herramienta simétrica solamente!
|
Router Bit Dimensions |
Max RPM |
|
2" (Less than 50) |
28,000 |
|
2" - 2-3/8" (50-60mm) |
22,000 |
|
2-3/8" - 2-3/4" (60-70mm) |
19,000 |
|
2-3/4" - 3-1/4" (70-80mm) |
16,000 |
|
3-1/4" - 3-5/8" (80-90mm) |
15,000 |
|
3-5/8" < (90-100mm) |
13,000 |
Note: Please also refer to
laser etching on router bit shank for most updated RPM speed rating.
| Availability | In Stock |
|---|---|
| Manufacturer | AMANA TOOL |
| Manufacturer Sku | 54297 |
