AMANA TOOL 54306 FLUTE BIT 3/4" RAD. 1/2 SHANK
$61.54
In stock
SKU
35524
Edge Fluting Router Bits
2 Flute with Ball Bearing Guide
This bit produces a fingernail flute, rather than a full
180° radius flute. Creates an interesting edge detail, and it can be used to
make small-scale cornice-type moldings. Use in a handheld or a table-mounted
router.
|
D |
R |
B |
C |
d |
L |
Tool No. |
|
3/4 |
5/16 |
1/2 |
1/8 |
1/2 |
2-3/4 |
54302 |
|
7/8 |
15/32 |
3/4 |
3/16 |
1/2 |
3 |
54304 |
|
7/8 |
3/4 |
1 |
3/16 |
1/2 |
3-1/4 |
54306 |
|
1 |
1-1/4 |
1-1/2 |
1/4 |
1/2 |
3-3/4 |
54308 |
Replacement bearing #47706
Max RPM Guide for Amana Tool® Router Bits
Do not exceed the maximum RPM shown for the particular tool
you are using.
Max RPM for symmetrical tool only!
No exceda la maxima velocidad (RPM) indicada para cada
herramienta.
Máximo RPM para la herramienta simétrica solamente!
|
Router Bit Dimensions |
Max RPM |
|
2" (Less than 50) |
28,000 |
|
2" - 2-3/8" (50-60mm) |
22,000 |
|
2-3/8" - 2-3/4" (60-70mm) |
19,000 |
|
2-3/4" - 3-1/4" (70-80mm) |
16,000 |
|
3-1/4" - 3-5/8" (80-90mm) |
15,000 |
|
3-5/8" < (90-100mm) |
13,000 |
Note: Please also refer to laser etching on router bit
shank for most updated RPM speed rating.
| Availability | In Stock |
|---|---|
| Manufacturer | AMANA TOOL |
| Manufacturer Sku | 54306 |
