AMANA TOOL 55420 2 PIECE CONCAVE STILE & RAIL
$147.71
In stock
SKU
35681
2 Piece Stile & Rail Router Bit Sets
2-Wing With Ball Bearing Guide
These types of sets utilizes two different cutters that are
'coped' to each other. Also included are extra cutters for trimming and
rabbeting and spacers if you decide to use the bearings similar to a
'reversible' set. With trim cutters #55448 & #55450 - use on 7/8" through 1"
stock use. For 5/8" through 7/8" stock, substitute trim cutters with spacers.
|
Pattern Type |
D |
R |
B |
d |
L |
Tool No. |
|
Bead |
1-5/8 |
3/16 |
1-1/16 |
1/2 |
3-5/16 |
55440 |
|
Pattern Type |
D |
R |
B |
d |
L |
Tool No. |
|
Concave |
1-5/8 |
1/4 |
1-1/16 |
1/2 |
3-5/16 |
55420 |
|
Pattern Type |
D |
R |
B |
d |
L |
Tool No. |
|
Ogee |
1-5/8 |
1/4 |
1-1/16 |
1/2 |
3-5/16 |
55430 |
|
Router Bit Dimensions |
Max RPM |
|
2" (Less than 50) |
28,000 |
|
2" - 2-3/8" (50-60mm) |
22,000 |
|
2-3/8" - 2-3/4" (60-70mm) |
19,000 |
|
2-3/4" - 3-1/4" (70-80mm) |
16,000 |
|
3-1/4" - 3-5/8" (80-90mm) |
15,000 |
|
3-5/8" < (90-100mm) |
13,000 |
Note: Please also refer to laser etching on router bit
shank for most updated RPM speed rating.
Individual Components
Quality Required for Tool No.
|
Order # |
Description |
55420 |
55430 |
55440 |
||||
|
55422 |
Concave Profile Cutter |
