AMANA TOOL MD10-806 HEAVY MITER 10"x80T 4+1 5/8"BO
$87.41
In stock
SKU
38365
Heavy-Duty Miter / Double Miter Saw
Blades
•
Carbide Tipped
•
4 ATB+R (4 Alternate Top Bevel Followed by 1
Raker)
•
Perfect for picture frame industry & shops
The A.G.E. Series Heavy-Duty Single/Double Miter blades
were designed especially for glass-smooth compound miters cuts in moldings and
picture frame stock for use in a miter box and single/double miter machines.
This style blade is the perfect choice for picture frame
and millwork shops. Unlike thinner miter blades which have a tendency to flex
and warp, throwing off the miter joint. Our Blades are stiffer and provide clean
burr-free cuts in wood, aluminum and non-ferrous metals. Special grind, minimal
run-out and tight side clearances all combine to yield perfect “GAP-FREE” miters
every time!
Specification
|
Tool No. |
Dia. |
Teeth |
Kerf mm |
Kerf Inch |
Plate mm |
Plate Inch |
Hook Angle |
Bore |
|
MD10-806 |
10" |
80 |
3.0 |
.118 |
2.5 |
.098 |
-5° |
5/8" |
|
MD12-816 |
12" |
80 |
3.0 |
.118 |
2.5 |
.098 |
-5° |
1" |
|
MD12-106 |
12" |
100 |
3.0 |
.118 |
2.5 |
.098 |
-5° |
1" |
|
MD12-106-5/8* |
12" |
100 |
3.0 |
.118 |
2.5 |
.098 |
-5° |
5/8" |
*Pistorius, CTD, Brevetti
Products shown in Bold indicate most popular saw blades.
| Availability | In Stock |
|---|---|
| Manufacturer | AMANA TOOL |
| Manufacturer Sku | MD10-806 |
