AMANA TOOL RC-1004 FLUSH TRIM 30MM CARBIDE 1/2 SH
$112.54
In stock
SKU
38765
Insert Flush Trim
Router Bits
2 Flute
In a production
environment, insert tooling reduces downtime to a minimum. Each throw-away knife
in this flush trimming bit has multiple edges. Rotate the knife to expose a
fresh cutting edge. Tips can be replaced at any time, even mid-job, without
changing the router setup.
Key Specifications
|
D |
B |
d |
L |
Replacement Knives (min. order 10ea.) |
Tool No. |
|
3/4 |
12mm |
1/4 |
2-1/8 |
AMA-12 |
RC-1000 |
|
3/4 |
30mm |
1/2 |
3-1/4 |
ICK-30 |
RC-1004 |
|
3/4 |
50mm |
1/2 |
4-5/16 |
RCK-151 |
RC-1006* |
* This tool is
meant for difficult work. The knives are held with 3 screws
Note: RC-1000 &
RC-1006 have four cutting edges per knife. #'s RC-1002 & RC-1004 have two
cutting edges per knife.
·
Torx® key included
- #5005
·
Replacement
bearing #47711
·
Replacement knife
screws #67115
·
Replacement
bearing screws #67176
Max RPM Guide for Amana Tool® Router Bits
Do not exceed the maximum RPM shown for the particular tool
you are using. Max RPM for symmetrical tool only!
No exceda la maxima velocidad (RPM) indicada para cada
herramienta. Máximo RPM para la herramienta simétrica solamente!
|
Router Bit Dimensions |
Max RPM |
|
2" (Less than 50) |
28,000 |
|
2" - 2-3/8" (50-60mm) |
22,000 |
|
2-3/8" - 2-3/4" (60-70mm) |
19,000 |
|
2-3/4" - 3-1/4" (70-80mm) |
16,000 |
|
3-1/4" - 3-5/8" (80-90mm) |
15,000 |
|
3-5/8" < (90-100mm) |
13,000 |
Note: Please
also refer to laser etching on router bit shank for most updated RPM speed
rating.
| Availability | In Stock |
|---|---|
| Manufacturer | AMANA TOOL |
| Manufacturer Sku | RC-1004 |
