BOSCH GTS1041A-09 REAXX™ 10" Worksite Table Saw w/ Active Response Technology, Gravity Rise Stand & Outfeed Support

10 In. REAXX™ Jobsite Table Saw with Gravity-Rise™ Wheeled Stand

The Bosch GTS1041A-09 REAXX™ 10 In. jobsite table saw kit builds on Bosch's heritage of award-winning table saw design while providing the injury-mitigation Active Response Technology™ platform, which delivers a rapid drop of the saw blade below the tabletop when it detects human flesh coming in contact with the blade. This high speed action helps to mitigate the potential of serious user injury. It does so without damaging the blade, and after activation, the system can be reset in less than 60 seconds. This technology reinforces the Smart Guard System, a modular blade guard that includes an adjustable riving knife, antikickback pawls and a barrier guard. The table saw features an enhanced SquareLock™ rip fence engineered for exact clamping and a more substantial feel similar to a cabinet-saw-grade glide. It also has spring-loaded pre-squaring that aligns the rip fence to the blade before locking, for enhanced cutting trueness. It includes a rear outfeed for 18 In. of additional rear material support. The included Gravity-Rise™ Wheeled Table Saw Stand manages tough terrain for trouble-free transport of the table saw between jobsites, and provides easy setup and fast take down. The saw's onboard control panel is an easy-to-understand LED light display that integrates Near Field Communication (NFC) technology. This allows NFC-enabled phones to communicate information from the onboard control system – such as system activations, servicing needs and instructions. The saw features a beefy 15-amp, 4.0-hp max motor producing 3,650 rpm. It includes additional advanced electronics that provide soft-start to manage motor start-up and Constant Response™ circuitry to maintain speed under load. The saw works with nearly all standard 10 In. fine finish and construction-grade blades and stacked dado blades, it has a 25 In. rip fence capacity, and it has onboard storage for all necessary parts, instructions and wrenches

Includes

• (1) Gravity-Rise™ Wheeled Stand
• (1) Rear Outfeed Support
• (1) 10 In. 40-Tooth Saw Blade
• (1) Dual-Activation Cartridge
• (1) Miter Gauge
• (1) Rip Fence
• (1) Barrier-Guard Device
• (1) Anti-Kickback Pawls
• (1) Push Stick
• (1) Dual-Activation Cartridge Wrench
• (1) Blade Wrench
• (1) Hex Wrench
• (1) Throat Plate Kit

Technical Data

Specifications

Benefits

• Active Response Technology™ – mitigates injury to user in case of blade contact, dropping the blade under the table with no blade damage
• Easy system reset – takes less than 60 seconds after blade drop, with no damage to the blade
• Dual-activation cartridge unit – two single-shot cylinders for two separate activations with each cartridge
• Portability – works seamlessly with the included Gravity-Rise™ Wheeled Stand for easy jobsite mobility, with single-action setup and take down
• Smart Guard System – riving knife and anti-kickback pawls provide protection when a kickback occurs, while the overhead guard provides a barrier helping to deter blade contact
• Powerful 15-amp 4.0-hp max motor – delivers 3,650 rpm and the power required for ripping in fine and rough carpentry materials, including standard 10 In. blade and dado applications
• Enhanced SquareLock™ rip fence – engineered for enhanced clamping and trueness with precision improvements for pre-squaring prior to locking
• Large cast aluminum top – provides increased work space and material support with a 25 In. ripping capacity
• Rear outfeed – hardened metal saw extension extends 18 In. and retracts for compact storage
• Onboard System Control – easy-to-understand saw status with intuitive LED lighted display
• Phone app – communicates information from control system to NFC-enabled phone, including number of system activations, servicing needs, access to instructions and other information
• Constant Response™ circuitry – to maintain speed under load and overload protection
• Soft-start circuitry – manages the intensity of motor start-up and minimizes the likelihood of tripping circuit breaker
• Onboard storage – access to all included parts, with additional cartridge storage, manual and system reset instructions
• Arbor lock – allows for easy blade changes with arbor lock and blade wrench located onboard
• Easy blade adjustment – located on top of table near throat plate, direct accessibility for easy blade parallel adjustment
• Convenient toolless throat plate lock – locks throat plate quickly and makes removal and reinstallation easy
• T-slot miter gauge combined with T-slot rail – allows for better control and support during miter gauge applications
• Durable sub base – increases tool life by handling tough jobsite conditions
