BOSCH MRF23EVS 2.3 HP Electronic VS Fixed-Base Router w/ Trigger Control
MRF23EVS 2.3 HP Fixed-Base Router
·
10,000-25,000 RPM; 2.3 HP (Max Tool)
·
Trigger Control System - Trigger power switch
located in handle for enhanced control
·
Versatile Fixed-Base Depth Adjustment - Features
1-5/8" continuous microfine adjustment range & wrench for adjustments through
top of optional router table
·
Always-On LED Lighting - For enhanced visibility
in bit area
·
Precision Centering Design – Makes it easy to
keep bit on cutline when using jigs, templets, dovetail fixtures and similar
guidance devices
·
Two-Stage Quick Clamp System - For fast tool-free
conversion
·
Soft-start — Reduces start-up torque
·
Variable speed dial — For matching speed to
workpiece and task
·
Constant-Response™ Circuitry — Maintains constant
speed under load
·
Contoured soft grip handles — For enhanced
control and comfort
·
Fixed base has threaded holes for mounting to
router table positioned in common 3-hole pattern.
·
Cord Swivel - For added mobility
Specifications
|
Amperage |
15 |
|
Base Diameter |
6" Fixed |
|
Base Opening |
3-3/4" |
|
Collet Capacity |
1/2" and 1/4" |
|
Cord Length |
10" ft. (3 m) |
|
FixedBase Depth Range |
1-5/8" |
|
Manuals |
MRC23EVSK, MRF23EVS, MRP23EVS (EN) #19418 (D#19418) |
|
Max. Motor HP |
2.3 HP |
|
No Load RPM |
10,000-25,000 |
|
Rating |
120V AC |
|
Service Baretool Numbers |
3601F24010 |
|
Serviceable |
Yes |
|
Subbase Opening |
2" |
Includes:
·
Fixed Base (MRF01)
·
1/4" Self-Releasing Collet Chuck -- 2 610 906 283
·
1/2" Self-Releasing Collet Chuck -- 2 610 906 284
·
16mm Shaft Wrench -- 2 610 991 388
·
24mm Collet Nut Wrench-- 2 610 992 417
·
T-Handle Hex Height Adjustment Wrench --
2610923193
·
M4 Screws for table mounting (3)
| Availability | In Stock |
|---|---|
| Manufacturer | BOSCH |
| Manufacturer Sku | MRF23EVS |
