BOSCH PL1632 3-1/4" Planer
3-1/4 In. Planer
Benefits
·
Powerful planer with 6.5 amp rating and 16,500
RPM speed for fast stock removal and smooth finish in soft and hard woods
·
Dual-mount guide fence with protective shield for
steady planing of door edges with plastic overshoe to prevent marring of door
face
·
First-ever power planer to have ambidextrous
"lock-off" release button to help avoid accidental starts, plus a lock-on button
for extended operation
·
Spring-loaded stand elevates tool to protect
blade and tool resting spot; special shape allows easy entry in middle of
workpiece
·
Ball-joint cord swivel for enhanced ease of
positioning the tool and cord and for cord durability
·
Ratcheting depth knob allows fool-proof setting
of depth increments from 0 to 1/16" (1.6 mm) within one revolution, eliminating
the need to re-zero the depth
·
Aluminum front and rear shoes precision-machined
together after assembly to ensure accuracy
·
Equipped with reversible Bosch Woodrazor®
micrograin mini carbide blade, which resists fractures from nail and staple
strikes and lasts up to two times longer on PL1632 than standard carbide blades
on other planers
·
Electronically-counterbalanced single-blade
system automatically positions blade at ideal cutting angle eliminates uneven
planing caused by misaligned blades, reduces drag, and provides fast operation
and smooth finish
·
Separate inch and metric depth scales for easy
setting of planing depth
·
Machined groove for chamfering
·
Optimally-angled handle for forward motion of
tool with softgrip for comfort
·
Poly micro V drive belt provides enhanced belt
durability
Specifications
|
Amperage |
6.5 |
|
Battery/Charger |
Not Included |
|
Case Type |
No Case Included |
|
Certifications |
CSA |
|
Cord Length |
10 ft |
|
Height |
6.5" |
|
Length |
11.4" |
|
No Load RPM |
16,500 |
|
Planing Depth |
0" to 1/16" (1.5 mm) |
|
Planing Width |
0" to 3-1/4" |
|
Rabbet Depth |
5/16" |
|
Rabbet Width |
3-1/4" |
|
Rating |
120V AC |
|
Shoe Length |
11.125 |
|
Voltage |
120V |
|
Warranty |
Limited 1 Year |
|
Weight |
6.3 lb |
|
Width |
6" |
Includes
(1) -- Reversible Woodrazor™ Blade - PA1202
(1) -- Dual-Mount Guide Fence -- 2609111859
(1) -- No-Mar Plastic Overshoe for Fence -- 2609101407
(1) -- Shavings Bag - 2605411035
(1) -- Blade Wrench -- 2607950003
| Availability | In Stock |
|---|---|
| Manufacturer | BOSCH |
| Manufacturer Sku | PL1632 |
