COILHOSE PNEUMATICS 26R3 3/8" Regulator
$41.03
Out of stock
SKU
344950
Image is for reference only! Product may be
different. Please contact us for further questions.
26 Series Regulators
The 26 Series Regulators offer a balance of compact size
and optimum flow. Utilizing a 3/8" die cast aluminum body, this series is
perfect for applications where performance, small size and low cost are
important. Available in 1/4" and 3/8" port sizes.
Specifications
Maximum Supply
Pressure: . . . . .250 PSI
Maximum Operating
Temp.: . . . . .250° F
Materials:
Adjusting Knob: . . .
. . . .High Impact Plastic
Body: . . . . . . . .
. . . . . . .Zinc Die Cast
Height: . . . . . . .
. . . . . . . . . .4"
Maximum Diameter: . .
. . . .2"
Bowl Capacity: . . .
. . . . . . .1/2 lb.
Regulator Pressure Ranges:
0-125 - Standard
0-60 - Optional
0-25 - Optional
|
Description Pipe Size |
Model |
|
1/4" |
26R2 |
|
3/8" |
26R3 |
Features
·
Balanced poppet valve design assures superior
performance.
·
0-125 PSI, 0-60 PSI, 0-25 PSI pressure ranges
available.
·
Self-relieving feature prevents excessive
pressure build-up.
·
Locking adjustment knob. Panel mount and gauge
options available.
·
Gauge ports can be used as
secondary outlet ports.
WARNING: Although
polycarbonate bowls are capable of withstanding extreme physical abuse, they are
susceptible to damage and may possibly burst when subjected to some cleaning
products and synthetic oils, particularly phosphate esters. Should there be any
questions regarding their compatibility with your applications, consult the
factory or use a metal bowl.
Options
Options Suffix
Gauge G
Extra Low Pressure Spring (0-25) PSI J
Low Pressure Spring (0-60) PSI L
Panel Mount P
Options are indicated by adding a dash followed by the
corresponding suffix(es) in alphabetical order to the model number.
| Availability | Out of Stock |
|---|---|
| Manufacturer | COILHOSE PNEUMATICS |
| Manufacturer Sku | 26R3 |
