COILHOSE PNEUMATICS MF2 1/4" Miniature Filter

Image is for reference only! Product may be different. Please contact us for further questions.

Miniature Series Filters

The Miniature Series Filters are designed for applications where space is limited and flow requirements are low. They excel in control panels and miniature circuitry. Each unit can be disassembled by hand for easy maintenance.

 Specification

Maximum Supply Pressure:

Plastic Bowl: . . . . . . . . . . .150 PSI

Metal Bowl: . . . . . . . . . . . .250 PSI

Maximum Operating Temp.:

Plastic Bowl: . . . . . . . . . . .120° F

Metal Bowl: . . . . . . . . . . . .250° F

Filter Element:

Standard: . . . . . . . . . . . . .20 Micron

Optional: . . . . . . . . . . . . . .5 Micron

Materials:

Plastic Bowl: . . . . . . . . . .Polycarbonate

Metal Bowl: . . . . . . . . . . .Zinc Die Cast

Body: . . . . . . . . . . . . . . . .Zinc Die Cast

Filter Element: . . . . . . . . .Porous

Polypropylene

Height: . . . . . . . . . . . . . . . . . . .4"

Maximum Diameter: . . . . . . . .1 1/2"

Bowl Capacity: . . . . . . . . . . . .1.5 oz.

Features

·         Compact size.

·         Available in 1/8" or 1/4" ports.

·         Tough die cast zinc body.

·         20 micron or 5 micron filter element.

·         Manual drain for quick and easy fluid removal.

·         Metal bowl option. 1.5 oz. bowl capacity.

?                Options:

Options                                Suffix

Metal Bowl                         M

Filter Element                    X

Options are indicated by adding a dash followed by the corresponding suffix(es) in alphabetical order to the model number.
