COILHOSE PNEUMATICS R140 1/4" Regulator, General Purpose Series
Image is for reference only! Product may
be different. Please contact us for further questions.
General Purpose Series Regulators
The General Purpose Series Regulators are ideal
where pressure must be held constant over a wide variation of flow. Zinc die
cast bodies offer excellent durability for most industrial applications.
Features
·
Holds
pressure constant over wide variations in flow.
·
0 - 125 PSI
pressure range.
·
Two 1/4
inch gauge ports.
Specifications
|
Pipe Size |
Model |
|
1/4"
|
R140** |
|
3/8"
|
R380** |
|
1/2" |
R120* |
|
3/4"
|
R340 |
|
1"
|
R100 |
|
1 1/4" |
R1140 |
|
1 1/2" |
R1120 |
|
2" |
R2000*** |
Maximum Supply Pressure: . .300 PSI
Maximum Operating Temp.: . .120° F
Materials:
Adjusting Knob: . . . . . . . .Brass
Body: . . . . . . . . . . . . . . . .Zinc Die Cast
Supply 100 PSI
Pressure Drop
Regulated Pressure 5 10 15
1/4"
10 18 40
3/8"
10 18 50
1/2"
10 18 60
3/4" &
1"
20 40 120
1 1/4" & 1 1/2"
20 120 240
2"
400 750 1200
SCFM
Note: All values are approximate.
*Master pack is eight units per carton.
**Master pack is twelve units per carton.
***R2000 (2") regulator requires a pilot regulator
to control the reduced pressure outlet.
WARNING:
Although polycarbonate bowls are capable of
withstanding extreme physical abuse, they are susceptible to damage and may
possibly burst when subjected to some cleaning products and synthetic oils,
particularly phosphate esters. Should there be any questions regarding their
compatibility with your applications, consult the factory or use a metal bowl.
| Availability | In Stock |
|---|---|
| Manufacturer | COILHOSE PNEUMATICS |
| Manufacturer Sku | R140 |
