CP - CHICAGO PNEUMATIC 8941077290 CP7729 3/8" IMPACT WRENCH
$199.00
In stock
SKU
2085814
CP7729 - Side-2-Side: unique reverse technology for perfect balance &
power
Features
·
The most powerful 3/8" of its class for general
maintenance
·
Maximize operator comfort with an extremely light
and well balanced design
·
Most convenient and unique reverse technology in
the market
·
3/8" compact impact wrench for general
maintenance
·
Twin hammer clutch
·
Composite handle and magnesium clutch housing
·
S2S technology and 3 positive power settings
·
Full teasing trigger
Technical
description
|
Part number |
8941077290 |
|
|
Model |
CP7729 |
|
|
Handle type |
Pistol |
|
|
Square drive |
3/8" |
|
|
Working Torque Range (fwd) |
68-407 Nm |
50-300 |
|
Maximum Torque (reverse) |
563 Nm |
415 ft.lbs |
|
Free speed |
9400 rpm |
|
|
Blows per minute |
1700 |
|
|
Net weight |
1.25 kg |
2.78 lb |
|
Power/weight ratio |
469.2 Nm/kg |
149.3 ft.lb/lb |
|
Length |
163 mm |
6.4" |
|
Side to center |
26 mm |
1" |
|
Average air consumption |
2.4 l/s |
5 cfm |
|
Actual air consumption |
9.4 l/s |
20 cfm |
|
Air inlet thread size |
0.25 " |
|
|
Min. hose size |
10 mm |
3/8" |
|
Noise level |
91 db(A) |
|
|
Sound Power |
102 db(A) |
|
|
Vibration a (ISO-28927-2) |
6.4 m/s² |
|
|
Vibration K (ISO-28927-2) |
1.9 m/s² |
|
|
Socket retainer |
Friction ring |
|
|
Clutch type |
Twin hammer |
|
| Availability | In Stock |
|---|---|
| Manufacturer | CP - CHICAGO PNEUMATIC |
| Manufacturer Sku | 8941077290 |
