CP - CHICAGO PNEUMATIC 8941077826 CP7782-6 1" Impact Wrench 6" Anvil
$747.11
In stock
SKU
2085846
CP7782-6 - High Torque & Comfort
Features
·
High efficiency
motor, yet economical with durable reinforced clutch mechanism
·
Durable impact
wrench with great power for the toughest jobs on heavy vehicles
·
1" straight impact
wrench with 6" extended anvil
·
1920 ft.lbs - 2600
Nm of maximum torque in reverse
·
Pinless closed
reinforced rocking dog impact mechanism
·
Socket retainer
ring combined with hole retainer
·
Ergonomic side
handle
·
Full teasing
trigger
·
Regulator with
integrated forward/reverse with 3-position power settings in both directions
Technical Description
|
Part number |
8941077826 |
|
|
Model |
CP7782-6 |
|
|
Over carton |
670*245*130 |
26,35*9,6*5,11 |
|
Handle type |
D-Handle Inside Trigger |
|
|
Square drive |
1" |
|
|
Working Torque Range (fwd) |
500 - 2000 Nm |
370 - 1475 |
|
Maximum Torque (reverse) |
2600 Nm |
1920 ft.lbs |
|
Free speed |
5200 rpm |
|
|
Blows per minute |
500 |
|
|
Net weight |
11.6 kg |
25.55 lb |
|
Power/weight ratio |
250 Nm/kg |
83.8 ft.lb/lb |
|
Length |
520 mm |
20.4" |
|
Average air consumption |
4.8 l/s |
10 cfm |
|
Actual air consumption |
19.2 l/s |
40.7 cfm |
|
Air inlet thread size |
0.5 " |
|
|
Min. hose size |
13 mm |
1/2" |
|
Noise level |
100 db(A) |
|
|
Sound Power |
111 db(A) |
|
|
Vibration a (ISO-28927-2) |
7.8 m/s² |
|
|
Vibration K (ISO-28927-2) |
1.8 m/s² |
|
|
Socket retainer |
Dual |
|
|
Clutch type |
Pin less closed rocking dog |
|
|
Bolt size |
M32 |
|
|
Box dimensions |
670*245*130 |
26,35*9,6*5,11 |
| Availability | In Stock |
|---|---|
| Manufacturer | CP - CHICAGO PNEUMATIC |
| Manufacturer Sku | 8941077826 |
