DIAMOND PRODUCTS 01806 4246055 - M-1 ANCHOR DRILL STAND ONLY
$916.56
In stock
SKU
459652
M-1 COMPLETE CORE RIGS 10”
Our Best Selling Core Rig!
Features:
·
2-1/2” square column (mast) with black oxidized
finish
·
6” wheels for easy mobility
·
Dual switch/outlet control panel with amp meter
(except for CB700 models with LED amp meter)
·
Vacuum pump for quick mounting to flat surface
without drilling an anchor hole (included with combination rig)
·
4 leveling screws on the base
·
Up to 14” bit capacity with one spacer block
Benefits:
·
Slide handle allows for drilling in tight areas
·
Combination base is a quick change over from
vacuum to anchor base
·
Great for the general contractor or pro
contractor
·
Ceiling jack helps keep the rig in place as a
backup for anchoring or vacuuming the base down (used with a brace piece - 2 x 4
or other material)
|
COMPLETE M 1
COMBINATION DRILL RIGS WITH VACUUM PUMP |
|||||||||||||||
|
Model # |
Motor |
Motor RPM |
Combo Rig Part # |
Cat # |
Uncrated/Crated Weight (lbs.) |
||||||||||
|
M1C-20-CB-V |
20 Amp Core Bore CB748 |
350/900 |
4245055 |
01789 |
134/145 |
||||||||||
|
M1C-20-CB700-V |
20 Amp Core Bore CB700 |
400/930 |
4245099 |
30076 |
136/149 |
||||||||||
|
M1C-20-CB700-V2 |
20 Amp Core Bore CB700 (no control panel) |
400/930 |
4245102 |
30097 |
125/136 |
||||||||||
|
M1C-20-CB700-VA 20 |
Amp Core Bore CB700 (with angle mast) |
400/930 |
4245101 |
30078 |
129/140 |
||||||||||
|
M1C-20-MW4004-V |
20 Amp Milwaukee |
300/600 |
4245048 |
01784 |
129/140 |
||||||||||
|
M1C-20-MW4096-V |
20 Amp Milwaukee |
450/900 |
4245059 |
01794 |
129/140 |
||||||||||
|
M1C-20-MW4005-V |
20 Amp Milwaukee |
600/1200 |
4245049 |
01785 |
129/140 |
||||||||||
|
M1C-15-MW4097-V |
15 Amp Milwaukee |
500/1000 |
4245051 |
01787 |
129/140 |
||||||||||
|
M1C-23-DK22-V |
23 Amp Weka DK22 |
550/1120/1680 |
4245053 |
47173 |
117/135 |
||||||||||
|
M1C-23-DK22S-V |
23 Amp Weka DK22S |
800/1640/2430 |
4245046 |
50138 |
117/135 |
||||||||||
|
COMPLETE M 1
COMBINATION DRILL RIGS WITHOUT VACUUM PUMP |
|||||||||||||||
|
M1C-20-CB |
20 Amp Core Bore CB748 |
350/900 |
4245071 |
65862 |
119/125 |
||||||||||
|
M1C-20-CB700 |
20 Amp Core Bore CB700 |
400/930 |
4245100 |
30077 |
114/120 |
||||||||||
|
M1C-20-MW4004 |
20 Amp Milwaukee |
300/600 |
4245072 |
75375 |
108/114 |
||||||||||
|
M1C-20-MW4096 |
20 Amp Milwaukee |
450/900 |
4245073 |
67092 |
108/114 |
||||||||||
|
M1C-20-MW4005 |
20 Amp Milwaukee |
600/1200 |
4245074 |
74708 |
108/114 |
||||||||||
|
M1C-15-MW4097 |
15 Amp Milwaukee |
500/1000 |
4245075 |
70125 |
108/114 |
||||||||||
|
M1C-23-DK22 |
23 Amp Weka DK22 |
550/1120/1680 |
4245077 |
71962 |
107/113 |
||||||||||
|
M1C-23-DK22S |
23 Amp Weka DK22S |
800/1640/2430 |
4245078 |
72583 |
107/113 |
||||||||||
|
COMPLETE M 1
ANCHOR DRILL RIGS |
|||||||||||||||
|
M1A-20-CB |
20 Amp Core Bore CB748 |
350/900 |
4245001 |
01774 |
98/104 |
||||||||||
|
M1A-20-CB700 |
20 Amp Core Bore CB700 |
400/930 |
4245098 |
30070 |
98/104 |
||||||||||
|
M1A-20-MW4004 |
20 Amp Milwaukee |
300/600 |
4245009 |
47162 |
91/97 |
||||||||||
|
M1A-20-MW4096 |
20 Amp Milwaukee |
450/900 |
4245003 |
01776 |
91/97 |
||||||||||
|
M1A-20-MW4005 |
20 Amp Milwaukee |
600/1200 |
4245010 |
01782 |
91/97 |
||||||||||
|
M1A-15-MW4097 |
15 Amp Milwaukee |
500/1000 |
4245006 |
01780 |
91/97 |
||||||||||
|
M1A-23-DK22 |
23 Amp Weka DK22 |
550/1120/1680 |
4245008 |
52339 |
95/100 |
||||||||||
|
M1A-23-DK22S |
23 Amp Weka DK22S |
800/1640/2430 |
4245011 |
66795 |
95/100 |
||||||||||
CB700 Rigs do not include a control panel.
CB700 has a built-in amp meter.
Drill stand only
includes: Base, column (mast), carriage, ceiling jack, motor mount plate and
wheels
Complete combination
rig includes: Combo anchor/vacuum base, drill motor, column (mast),
carriage, motor mount, control panel, vacuum pump, vacuum gasket, ceiling jack
and wheel kit
Complete anchor rig includes: Small
anchor base, drill motor, motor mount, column (mast), carriage, control panel,
ceiling jack and wheel kit
| Availability | In Stock |
|---|---|
| Manufacturer | DIAMOND PRODUCTS |
| Manufacturer Sku | 01806 |
