HONDA WB20 Honda OHV commercial engine 152 gal./min. capacity
WB20
(WB20XT2A,
WB20XT3 )
Features
·
General
purpose, centrifugal 2" pump
·
Easy starting
Honda OHV commercial engine
·
152 gal./min.
capacity
·
Durable
silicon carbide mechanical seal
·
Cast iron
volute and impeller
Easy starting Honda OHV commercial engine
·
The durable Honda GX series
commercial grade engine is easy starting and provides ample power for the
toughest conditions.
Durable silicon carbide mechanical seal
·
The WB20 features
abrasion-resistant silicone-carbide seals for extended wear.
Cast iron volute and impeller
·
The rigid-mount cast iron
volute reduces case wear, increasing the life of the pump.
Heavy duty full frame protection
·
Protects the pump, while
offering a convenient tie down location for transport.
Isolation mounted engine and pump
·
High performance mounts
minimize vibration, keeping the pump from “walking” away or “burying” itself in
soft soil conditions. The reduced vibration also reduces wear on components,
increasing the pump's durability.
Protected by Honda Oil Alert®
·
Protects the pump by shutting
the engine off when low oil is detected.
3 year residential/commercial warranty
·
You can rest easy, knowing
your pump is covered from top to bottom for 3 full years.
Large strainer
·
The strainer allows up to 8
mm (5/16 in.) solids to pass through, helping to prevent clogging.
Specifications
|
Engine |
GX120 |
|
Displacement |
118cc |
|
Bore and stroke |
2.4" x 1.7" |
|
Compression Ratio |
8.5:1 |
|
Oil Alert |
Std |
|
Pump type |
Centrifugal, Self-priming |
|
Volute |
Rigid Mounted Cast Iron |
|
Impeller |
Cast Iron |
|
Mechanical Seal (Pump case / impeller) |
Silicon Carbide/Silicon Carbide |
|
Priming time |
110 sec @ 16.4 ft. |
|
Drive system |
Direct |
|
Discharge capacity |
152 gal/min. |
|
Suction port diameter |
2" NPT |
|
Discharge port diameter |
2" NPT |
|
Total head lift |
92 ft. |
|
Suction head lift |
26 ft. |
|
Maximum pressure |
40 psi |
|
Solids handling |
N/A |
|
Dimensions (LxWxH) |
17.9" x 14.4" x 16.5" |
|
Dry weight |
46 lb. |
|
Strainer Part # |
78325-YG3-000 |
|
Residential Warranty |
3 years |
|
Commercial Warranty |
3 years |
Accessories
·
A wide variety of hose kits, couplers,
adaptors, and other accessories are available.
| Availability | Out of Stock |
|---|---|
| Manufacturer | HONDA |
| Manufacturer Sku | WB20 |
