HONDA WB30 Honda OHV commercial engine 275 gal./min. capacity

$699.00
In stock
SKU
1841462

WB30

(WB30XT2A, WB30XT3 )

Features

·         General purpose, centrifugal 3" pump

·         Easy starting Honda OHV commercial engine

·         275 gal./min. capacity

·         Silicon carbide mechanical seal

·         Cast iron volute and impeller



Easy starting Honda OHV commercial engine

·         The durable Honda GX series commercial grade engine is easy starting and provides ample power for the toughest conditions.

Durable silicon carbide mechanical seal

·         The WB20 features abrasion-resistant silicone-carbide seals for extended wear.

Cast iron volute and impeller

·         The rigid-mount cast iron volute reduces case wear, increasing the life of the pump.

Heavy duty full frame protection

·         Protects the pump, while offering a convenient tie down location for transport.

Isolation mounted engine and pump

·         High performance mounts minimize vibration, keeping the pump from “walking” away or “burying” itself in soft soil conditions. The reduced vibration also reduces wear on components, increasing the pump's durability.

Protected by Honda Oil Alert®

·         Protects the pump by shutting the engine off when low oil is detected.

3 year residential/commercial warranty

·         You can rest easy, knowing your pump is covered from top to bottom for 3 full years.

Large strainer

·         The strainer allows up to 8 mm (5/16 in.) solids to pass through, helping to prevent clogging.

Specifications

Engine

 GX160

Displacement

 163cc

Bore and stroke

 2.7" x 1.8"

Compression Ratio

 8.5:1

Oil Alert

 Std

Pump type

 Centrifugal, Self-priming

Volute

 Rigid Mounted Cast Iron

Impeller

 Cast Iron

Mechanical Seal (Pump case / impeller)

 Silicon Carbide/Silicon Carbide

Priming time

 150 sec @16.4 ft.

Drive system

 Direct

Discharge capacity

 275 gal/min.

Suction port diameter

 3" NPT

Discharge port diameter

 3" NPT

Total head lift

 85 ft.

Suction head lift

 26 ft.

Maximum pressure

 37 psi

Solids handling

 N/A

Dimensions (LxWxH)

 20.1"x 15.2" x 17.9"

Dry weight

 60 lb.

Strainer Part #

 78325-YG4-000

Residential Warranty

 3 years

Commercial Warranty

 3 years

Accessories

·         A wide variety of hose kits, couplers, adaptors, and other accessories are available.



More Information
Availability In Stock
Manufacturer HONDA
Manufacturer Sku WB30
