HONDA WH20 Honda OHV commercial engine 134 gal./min capacity
$799.00
In stock
SKU
1841465
WB20
(WH20XK2,
WH20XK1AC1 )
Features
·
High pressure
2" pump
·
Easy starting
Honda OHV commercial engine
·
134 gal./min
capacity
·
61 psi max.
·
Cast iron
volute and impeller
High pressure - ideal for sprinklers or nozzles
·
With a maximum pressure of 61
psi, the WH20 is designed for a variety of applications requiring high pressure.
Easy starting Honda OHV commercial engine
·
The durable Honda GX series
commercial grade engine is easy starting and provides ample power for the
toughest conditions.
134 gal./min. capacity
Cast iron volute and impeller
·
The rigid-mount cast iron
volute reduces case wear, increasing the life of the pump.
Easy carry handle
·
The WH20 is easy to transport
wherever you need it.
Lightweight aluminum case
3 year residential/commercial warranty
·
You can rest easy, knowing
your pump is covered from top to bottom for 3 full years.
Specifications
|
Engine |
GX160 |
|
Displacement |
163cc |
|
Bore and stroke |
2.7" x 1.8" |
|
Compression Ratio |
8.5:1 |
|
Oil Alert |
N/A |
|
Pump type |
High Pressure, Centrifugal,
Self-priming |
|
Volute |
Rigid Mounted Cast Iron |
|
Impeller |
Cast Iron |
|
Mechanical Seal (Pump case / impeller) |
Carbon/Ceramic |
|
Priming time |
60 sec. @ 16.4 ft. |
|
Drive system |
Direct |
|
Discharge capacity |
134 gals./min. |
|
Suction port diameter |
2" NPT |
|
Discharge port diameter |
2" NPT |
|
Total head lift |
141 ft. |
|
Suction head lift |
26 ft. |
|
Maximum pressure |
61 psi |
|
Solids handling |
N/A |
|
Dimensions (LxWxH) |
16.7" x 14.8" x 15.9" |
|
Dry weight |
51.8 lbs. |
|
Strainer Part # |
78325-YB7-702 |
|
Residential Warranty |
3 years |
|
Commercial Warranty |
3 years |
Accessories
·
A wide variety of hose kits, couplers,
adaptors, and other accessories are available.
| Availability | In Stock |
|---|---|
| Manufacturer | HONDA |
| Manufacturer Sku | WH20 |
