JET TOOLS 354401 J-2530, 15" Bench Model Drill Press 115V 1Ph -LTL
$899.00
Out of stock
SKU
1522336
J-2530 15" BENCH MODEL DRILL PRESS 3/4HP,115V
The J-2530 15" Bench Drill Press boasts a 3/4HP motor and
tilting table. Simple yet powerful, the J-2530 has a cast iron head and large
quill - allowing greater accuracy.
Details
·
Cast iron head
·
Large quill allows greater accuracy
·
Head casting features a permanently lubricated
ball bearing spindle assembly, using four heavy duty ball bearings in an
enclosed quill for longer life.
·
Table tilts 45°
·
Large ground steel column diameter for maximum
head and table support
·
Hinged metal belt and pulley cover
·
Accurate depth stop displays inch/mm and has a
quick set bolt fast
·
5/8" Drill chuck and arbor
Specifications
|
Model Number |
J-2530 |
|
Brand |
Jet |
|
Overall Dimensions |
26 X 13-3/8
X 39 |
|
Height |
12 inch |
|
Width |
22.5 inch |
|
Length |
32 inch |
|
Net Weight |
157 pound |
|
Gross Weight |
163 pound |
|
Motor |
3/4HP, 1
PH, 115V |
|
Number of Spindle speeds |
16 |
|
Range of Spindle Speeds (RPM) |
200,290,350,430,500,580,640,720,800,870,1440,1630,1820,2380,2540,3630 |
|
Spindle Taper |
MT-2 |
|
Quill Diameter (in.) |
1-7/8 |
|
Column Diameter (in.) |
2-7/8 |
|
Base Dimensions (LxWxH/ in.) |
18 x
10-1/2 |
|
Drilling Capacity Cast Iron (in.) |
5/8 |
|
Drilling Capacity Mild Steel (in.) |
1/2 |
|
Quill Travel (in.) |
3-3/8 |
|
Distance Base to Spindle (in.) |
24 |
|
Table Size (in.) |
11-1/2 x
11-1/2 |
|
Distance Column to Spindle (in.) |
7-1/2 |
|
Chuck Size (in.) |
5/8 |
|
Drills to Center of Circle (in) |
15 |
|
Spindle Distance to Base (in.) |
24 |
|
Swing (in.) |
15 |
|
Max Distance - Spindle to Table (in) |
15-1/2 |
|
Table Dimensions |
11-1/2 x
11-1/2 |
| Availability | Out of Stock |
|---|---|
| Manufacturer | JET TOOLS |
| Manufacturer Sku | 354401 |
