JITOOL 640S 23GA. 1-9/16" Micro Pinner

Product Information

Compatibility with other companies

-          MAX : NF235A/23-35Series

-          BOSTITCH : HP118K/PT1312 Series

-          SENCO : FINISHPRO 10/CZ Series

Model  Specification

-          23GA Micro Pinner

-          640S

Feature

-          Compact and Lightweight

-          Side Loading Magazine

-          200 Pins Loading Magazine(2 Clips Loaded)

-          Adoption of Special Safety

-          Lever for User’s Perfect Safety(U.S.A Patent Pending)

Applications

-          Molding & Decorative

-          Trim

-          Glazing Strips & Window Beading

-          Dowel & Joing Pinning

-          Rattan Furniture

-          Mirror & Picture Frame Assembly

Specifications

-          Pin Capacity 200 Pins

-          Weight 2.65lbs (1.2Kg)

-          Dimensions

-          H : 7-7/8"(200mm) / L : 9-15/16"(252mm) / W : 1-7/8"(47mm)

-          Use Pin Type

-          23GA. 1-9/16" Headless Pinner (15~40mm)

-          Available Pin Name 615, 618, 622, 625, 630, 640

-          Available pressure 4.0kg.f/cm - 7.0kg.f/cm
