KLEIN VDV512-056 CoaxMap™ Kit

COAXMAP™ KIT FOR VDV SCOUT™ PRO TESTERS

Identify and map coaxial cable infrastructure (F-Connector), up to 19 locations. The fastest, most efficient way to identify multiple locations at one time. Heavy-duty design for long life and repeated connections. Remotes numbered 1 through 19 for fast and accurate identification. For use with VDV Scout™ Pro Testers (Cat. No. VDV501-053, VDV501-809, VDV501-068, VDV501-814 and VDV501-816). LanMap™ Kit for VDV Scout™ Pro Tester – 19 location RJ45 Remotes (VDV526-055) also available.

Specifications:

All dimensions are in inches and (millimeters) except where indicated.

Warnings:

·         Read, understand and follow all instructions, cautions and warnings attached to and/or packed with all test and measurement devices before each use.

·         Always wear approved eye protection.

·         Do NOT use on energized circuits or cabling systems.

·         Connecting the instrument to voltages above the Safety Extra Low Voltage range of less than 60V peak AC or DC may pose a safety hazard to the user.

·         The Ranger TDR internal components are protected up to 400V peak AC or DC. Connecting the instrument to voltages above this range may pose a safety hazard to the user and the instrument.
