KREG TOOL R3 Kreg Jig® R3 Pocket Hole System

Features

• Two Independent Positioning Sliders
• Nine Individual Depth Settings
• Two Wood Chip Relief Holes
• Included Clamp Pad Adapter
• Compact and Organized Carrying Case
• Hardened Steel Drill Guides w/ Lifetime Warranty

Specifications

• Body Material:
  Glass Filled Nylon
• Number of Drill Guides:
  2
• Drill Guide Spacings:
  7/8"
• Clamping Method
  Works with a wide variety of clamps
  Face Clamp™ for Clamp Pad Adapter
• Screw Centering Ability:
  1/2", 5/8", 3/4", 7.8", 1", 1-1/8", 1-1/4", 1-3/8", 1-1/2"
• Warranty:
  Lifetime Drill Guide Warranty

Perfect for repairs or building on-the-go!

The Kreg Jig® Jr. is an amazing repair jig and an exceptionally handy addition to any tool collection. Whether you’re crawling under a table to make a quick repair or taking Kreg Joinery™ on the road, the Jr.’s small design lets you work where you need to most.

Clamp Pad Adapter

The Kreg Jig® Jr. can be secured to the workpiece with any standard bar clamp or c-clamp. In addition, the Jr.’s Clamp Pad Adapter allows the jig to be attached directly to any Kreg Face Clamp™ for faster and more repeatable Pocket-Holes.

Material Thickness Setting

From thin drawer boxes and craft projects to stout 2x4’s, this jig can handle them all. Independent Easy-Press™ Positioning Sliders feature 9 separate depth settings, allowing you to easily join materials from 1/2” to 1-1/2” thick in 1/8” increments.

Organized Carrying Case

Comes with a durable plastic carrying case to keep things organized and to make sure that you always have the tool, drill bit, and screws on hand to complete your next project. As a bonus, we’ve molded a Depth Collar Gauge into the case for a handy reference.

Easy-Press™ Positioning Sliders

To set the jig properly, simply depress the button on the side of the jig and move the sliders so your material thickness is aligned with the arrow on the jig body. It’s that easy.

Glass-Reinforced Nylon Body

The blue body of the Kreg Jig® is actually made from a heavy-duty glass-reinforced nylon. This unique composite material offers the resiliency and flexibility you need without sacrificing the strength and durability Kreg customers have come to expect.

Superior Angle

Unlike competing jigs with a shallower angle of approach, the Kreg Jig® Jr. features an optimized drilling angle specifically designed to increase driving efficiency and minimize the overall size of the Pocket-Hole. The result is a compact Pocket-Hole, less than 1-1/2” in size.

Wood-Chip Relief

Sometimes the simplest things are the easiest to overlook. The Kreg Jig® Jr. includes 1 wood-chip relief hole for every Drill Guide hole, designed to keep the drill bit clear of excess wood chips, minimizing drill torque, increasing the longevity of your drill bits, and allowing you to complete a perfect Pocket-Hole in one plunge instead of three!

Hardened Steel Core

Drill Guides are subject to direct contact with the drill bit every time a Pocket-Hole is created. The core of every Kreg Jig® Jr. features hardened steel which carries an exclusive 100% Lifetime Guarantee. The Kreg Jig® Jr.’s core shrouds the bit and supports the workpiece through 100% of the drill-stroke. The end result is minimal bit deflection, reduced tear-out, and a clean, pluggable Pocket-Hole fit for finish work.

Kit Includes

Includes Kreg Jig® Jr., Clamp Pad Adapter, Stepped Drill Bit, 6” Driver Bit, Depth Collar, Allen Wrench, Starter Screw Set, all inside of a compact and durable carrying case.

Patent Pending, Patented 5,676,500
