LINCOLN ELECTRIC K2382-4 Ranger® 250 GXT Engine Driven Welder (w/Electric Fuel Pump)
$7,559.00
Out of stock
SKU
710333
XTra
Performance! XTra Power! XTra Protection!
Get all of
the XTras needed for construction and maintenance work. That's XTra welding
performance with 250 amps for AC or DC stick and DC wire welding and XTra power
with up to 11,000 watts peak for lights, grinders or high amperage equipment.
You also get XTra protection and quiet operation with the Lincoln enclosed case.
·
Totally Enclosed Case
o
Engine is
fully protected.
o
3 service
access doors.
o
Low Noise –
76.4 dBA sound level at 23 ft. (7 m). 100.7 dB sound power (Lwa) at rated
output.
o
Choose from
painted or stainless steel roof, case sides and engine doors.
·
Versatile AC/DC Welding
o
AC/DC welding
output for a broad range of stick electrode types.
o
Excellent AC
TIG welding with optional TIG Module and either a foot or hand Amptrol™ for
aluminum and other alloy welding.
o
MIG and
Flux-Cored capable (with optional equipment).
o
Remote ready!
6-pin connector and local/remote switch for remote control operation.
·
11,000 Watts Peak Single-Phase AC Generator
Power
o
Peak for
motor starting.
o
10,000 watts
continuous power for generator, plasma cutter or inverter welder.
o
Lights,
grinder, power tools.
·
23 HP Kohler® Gasoline Engine
o
2 cylinder, 4
cycle overhead valve air-cooled design.
o
Electric fuel
pump avoids vapor lock.
o
Oil drain
extension for easy oil changes.
o
12 gallon
tank for extended run times.
o
Electric fuel
gauge located on control panel makes it easy to check the fuel level during
operation and refueling.
·
Rugged Reliability
o
Welding and
AC Generator Outputs Rated at 104°F (40°C).
Processes
·
Stick, TIG, MIG, Flux-Cored, Gouging
Output
Input
Specifications
|
RATED OUTPUT |
250A AC/25V/100% 250A DC/25V/100% |
|
OUTPUT RANGE |
50-250A AC/DC |
|
GENERATOR OUTPUT |
11000 watts peak, 10000 watts continuous |
|
TYPE OF ENGINE |
Kohler OHV Command CH23S |
|
HP AND SPEED |
23@3600 |
|
CYLINDERS |
2 |
|
DIMENSIONS (H X W X D) IN |
29.9 in x 21.5 in x 42.3 in |
|
DIMENSIONS (H X W X D) MM |
(759 mm x 546 mm x 1074 mm) |
|
NET WEIGHT |
602.000 lbs. (273.067 kg.) |
Accessories
|
CATEGORY |
PRODUCT NUMBER |
PRODUCT NAME |
|
General |
K802N |
Power Plug Kit (20 amp) |
|
General |
K1816-1 |
Full-KVA Adapter Kit |
|
General |
K1690-1 |
GFCI Receptacle Kit |
|
General |
K1898-1 |
Spark Arrester Kit |
|
General |
K886-2 |
Canvas Cover (Large) |
|
General |
K1737-1 |
All Terrain Undercarriage |
|
General |
K1770-1 |
Factory Undercarriage |
|
General |
K1745-1 |
Welding Gas Cylinder, LPG Tank Holder |
|
General |
K2635-1 |
Small Two-Wheel Road Trailer with Duo-Hitch |
|
General |
K2639-1 |
Fender and Light Kit |
|
General |
K2640-1 |
Cable Rack |
|
Stick |
K704 |
Accessory Kit - 400 Amp |
|
Stick |
K875 |
Accessory Kit - 150 Amp |
|
TIG |
K1783-9 |
PTA-26V TIG Torch (25 ft 2pc) |
|
TIG |
KP509 |
Parts Kit |
|
TIG |
K1478-5 |
Square Wave TIG 175 TIG Welder |
|
TIG |
K2350-2 |
Invertec® V205-T AC/DC TIG Welder One-Pak |
|
Wire Feeder |
K2613-5 |
LN-25 PRO Wire Feeder Standard |
|
Wire Feeder |
K126-12 |
K126™ PRO Innershield® 350A FCAW-SS Welding Gun 15 ft 1/16-5/64 |
|
Wire Feeder |
KP1697-068 |
Drive Roll Kit .068 in (1.7 mm) Cored Wire |
|
Wire Feeder |
K2652-2-10-45 |
Magnum® PRO 350 Welding Gun Ready-Pak 15 ft 035-5/64 Liner |
|
Wire Feeder |
KP1696-1 |
Drive Roll Kit Combination .035 in / .045 in Solid Wire |
|
Wire Feeder |
K2473-1 |
POWER MIG® 180C MIG Welder |
|
Wire Feeder |
K2532-1 |
Magnum® 100SG Spool Gun, Air-Cooled |
|
Plasma Cutter |
K2808-1 |
Tomahawk® 1000 Plasma Cutter with Hand Torch |
| Availability | Out of Stock |
|---|---|
| Manufacturer | LINCOLN ELECTRIC |
| Manufacturer Sku | K2382-4 |
