LINCOLN ELECTRIC K2706-2 Outback® 185 Engine Driven Welder
$5,354.00
In stock
SKU
710584
Built For The
Outdoors!™
Great for
anyone who needs portable DC stick welding and AC generator power! The Low-Lift™
grab bars on both ends make lifting the Outback® 185 on and off truck beds easy.
The compact Outback® 185 is easy to start with all engine controls on the front
of the machine, and it’s easy to use for welding. Use the AC generator power for
a variety of applications described below with the large 6.8 gallon (25.7 liter)
fuel tank! Plug in a Lincoln Electric POWER MIG® 140C or POWER MIG® 180C for
wire welding too.
·
Low-Lift™ Grab Bars (Patent Pending)
o
More leverage
for lifting unit on and off truck beds.
o
Extra
protection against product damage.
o
Best in class
feature!
·
All Engine Controls on Front Control Panel
o
Easy access
for starting, especially when mounted on truck beds.
o
Front panel
includes electric start switch and engine choke control.
o
Best in class
feature!
·
1-1/4 in. (32 mm) Diameter Rugged Tube Frame
o
Great for
all-around sturdy protection.
o
Largest
diameter tube frame in its class!
o
Best in class
feature!
·
6.8 Gallon (25.7 Liter) Fuel Tank
o
For extended
run times, less frequent re-fueling.
o
Large fuel
fill opening for easy re-fueling too.
o
Best in class
feature!
·
Weld with up to 5/32 in. (4 mm) Stick
Electrode
o
Up to 185
amps of DC output for many applications.
·
5,700 Watts Peak AC Generator Power (5,200
Watts Continuous).
o
Many uses!
Grinder, work lights, pump, motor starting, or emergency power.
o
Plug in a
Lincoln Electric POWER MIG® 140C or POWER MIG® 180C for wire welding.
o
Plug in a
Lincoln Electric Tomahawk® 375 Air to cut metal.
Processes
·
Stick
Output
Input
Specifications
|
RATED OUTPUT |
130A DC/25V/60% 150A DC/25V/20% |
|
OUTPUT RANGE |
50-185A DC |
|
GENERATOR OUTPUT |
5700 watts peak, 5200 watts continuous |
|
TYPE OF ENGINE |
Kohler CH440 |
|
HP AND SPEED |
14 HP @ 3600 RPM |
|
CYLINDERS |
1 |
|
DIMENSIONS (H X W X D) IN |
25.6 in x 21.8 in x 31.5 in |
|
DIMENSIONS (H X W X D) MM |
(651 mm x 553 mm x 800 mm) |
|
NET WEIGHT |
295.000 lbs. (133.812 kg.) |
Accessories
|
CATEGORY |
PRODUCT NUMBER |
PRODUCT NAME |
|
General |
K875 |
Accessory Kit - 150 Amp |
|
General |
K2722-1 |
Undercarriage |
|
General |
K2819-1 |
Lift Bail Kit |
|
General |
K2804-1 |
Canvas Cover |
|
General |
K1690-1 |
GFCI Receptacle Kit |
|
Wire Feeder |
K2471-1 |
POWER MIG® 140C MIG Welder |
|
Wire Feeder |
K2473-1 |
POWER MIG® 180C MIG Welder |
|
Wire Feeder |
K2532-1 |
Magnum® 100SG Spool Gun, Air-Cooled |
|
Plasma Cutter |
K2806-1 |
Tomahawk 375 Air Plasma
Cutter |
| Availability | In Stock |
|---|---|
| Manufacturer | LINCOLN ELECTRIC |
| Manufacturer Sku | K2706-2 |
