LINCOLN ELECTRIC K2816-2 POWER MIG® 216 MIG Welder - 208/230/1/60, 220/1/50
$2,546.18
Out of stock
SKU
710641
Power MIG®. The Professional's ChoiceThe Power MIG® 216
offers the autobody and sheet metal fabrication industries top welding
performance with a host of professional features.
·
Diamond
Core Technology™ – Delivers a forgiving arc, excellent out-of-position arc
action, low spatter and a wide voltage sweet spot for steel, stainless steel or
aluminum.
·
MAXTRAC®
Cast Aluminum Industrial Wire Drive – Features dual driven rolls, regulated
wire feed speed control, brass-to brass connections and Lincoln’s 100% wire
supporting split wire guide system.
·
More
Output and Better Efficiency – Compare the best in class rated output, wide
amperage range and efficiency.
·
Spool Gun
Ready – Just remove the standard MIG gun and plug in the economical Magnum®
100SG spool gun for enhanced aluminum wire feeding performance.
New! Great
Value-Adding Features:
·
Coil Claw™ Cable Management system keeps your
work station neat.
·
Convenient top-mounted gun expendables tray.
·
All metal case front.
Top Features
·
The POWER MIG® 216 MIG welder is ideal for
flux-cored welding in autobody and sheet metal fabrication.
·
Diamond Core Technology™ – Delivers a Forgiving
Arc
·
MAXTRAC® Cast Aluminum Industrial Wire Drive
·
More Output and Better Efficiency
·
Coil Claw™ Cable Management system keeps your
workstation organized
Input Power
·
208/230/1/60
·
220/1/50
Processes
·
MIG, Flux-Cored
Output
Input
Specifications
|
INPUT POWER |
·
208/230/1/60
·
220/1/50 |
|
RATED OUTPUT |
170A/24VDC/60% 216A/22VDC/30% |
|
INPUT CURRENT |
33A 30A |
|
OUTPUT RANGE |
30-250A |
|
SOLID WIRE SIZE RANGE |
3/16 in. - 5/16 in. (4.8 mm - 7.9 mm) |
|
CORED WIRE SIZE RANGE |
5/16 in. - 1/2 in. (7.9 mm - 12.7 mm) |
|
WIRE FEED SPEED RANGE |
50-700 IPM (1.3 - 17.8 m/min) |
|
DIMENSIONS (H X W X D) |
32.56 in x 19.15 in x 39.92 in (827 mm x 487 mm x 1014 mm) |
|
NET WEIGHT |
250.000 lbs. (113.400 kg.) |
Included
·
Power MIG® 216 includes:
o
Magnum® PRO 250L gun and 15 ft. (4.5 m)
“quick-connect” cable assembly equipped with fixed gas nozzle assembly.
o
Top-mounted gun expendables tray.
o
Built-in undercarriage with easy-load gas
cylinder platform.
o
Work clamp and 10 ft. (3.0 m) cable.
o
10 ft. (3.0 m) 230V input power cable with plug.
o
Drive roll and wire guide to feed both .035 in. &
.045 in. (0.9 & 1.2 mm) wire.
o
Gas regulator and hose kit for argon blend gases.
(For use with CO2 shielding gas, order a Lincoln Electric S19298 CO2
o
shielding gas bottle adapter.)
o
Large color coded procedure recommendation sheet.
Accessories
|
CATEGORY |
PRODUCT NUMBER |
PRODUCT NAME |
|
General |
K466-6 |
Gun Connector Kit |
|
General |
K2703-1 |
POWER MIG Spool Gun Adapter |
|
General |
K468 |
Spindle Adapter for Small Spools |
|
General |
K1702-1 |
Dual Cylinder Mounting Kit |
|
General |
K2378-1 |
Canvas Cover (Medium) |
|
Wire Feeder |
KP1696-030S |
Drive Roll Kit .023-.030 in (0.6-0.8 mm) Solid Wire |
|
Wire Feeder |
KP1696-035S |
Drive Roll Kit .035 in (0.9 mm) Solid Wire |
|
Wire Feeder |
KP1696-045S |
Drive Roll Kit .045 in (1.1 mm) Solid Wire |
|
Wire Feeder |
KP1696-1 |
Drive Roll Kit Combination .035 in / .045 in Solid Wire |
|
Wire Feeder |
KP1696-2 |
Drive Roll Kit .040 in (1.0 mm) Solid Wire |
|
Wire Feeder |
KP1697-035C |
Drive Roll Kit .035 in (0.9 mm) Cored Wire |
|
Wire Feeder |
KP1697-045C |
Drive Roll Kit .045 in (1.1 mm) Cored Wire |
|
Spool Gun |
K2532-1 |
Magnum® 100SG Spool Gun, Air-Cooled |
|
Spool Gun |
K487-25 |
Magnum® SG Spool Gun, Air-Cooled, 25 ft. |
|
Spool Gun |
K2490-1 |
Magnum® 250LX Spool Gun, Air-Cooled, 25 ft. |
| Availability | Out of Stock |
|---|---|
| Manufacturer | LINCOLN ELECTRIC |
| Manufacturer Sku | K2816-2 |
