LINCOLN ELECTRIC K2857-1 Ranger® 225 Engine Driven Welder

Got It Covered!™ Enclosed-Case Welder

A great choice for getting the job done! For construction contractors, maintenance crews, farmers or ranchers, the Ranger® 225 does a variety of basic welding jobs. And with 10,500 watts of peak AC generator power, it handles a variety of other jobs: lights, grinder, Lincoln Electric inverter, plasma cutter (separate air supply needed) or emergency power. At your service – everyday!™

·         Totally Enclosed Case

o   Engine is fully protected.

o   3 service access doors.

o   Low Noise – 76.4 dBA sound level at 23 ft. (7 m). 100.7 dB sound power (Lwa) at rated output.

·         Versatile DC Welding

o   Smooth DC welding output for a broad range of stick electrode types.

o   MIG, Flux-Cored and TIG capable (with optional equipment).

·         10,500 Watts Peak Single-Phase AC Generator Power

o   Peak for motor starting.

o   9,000 watts continuous power for generator, plasma cutter or inverter welder.

o   Lights, grinder, power tools.

·         23 HP Kohler® Gasoline Engine

o   2 cylinder, 4 cycle overhead valve air-cooled design.

o   Oil drain extension for easy oil changes.

o   12 gallon tank for extended run times.

o   Only 1.3 gallons/hour at 210 amps DC, 25V, 100% duty cycle. Visual fuel level gauge on both sides of unit.

·         Rugged Reliability

o   Welding and AC Generator Outputs Rated at 104°F (40°C).

 Processes

·         Stick, TIG, MIG, Flux-Cored, Gouging
