LINCOLN ELECTRIC K449 LN-25 Wire Feeder
$5,607.85
In stock
SKU
710864
Top Features
·
Selectable dial
for setting low range
·
For use with
Magnum® flux-cored and MIG guns.
·
Automatic
overvoltage and motor overload shutdown protection.
·
Double-latched
case features an insulated gun holder and easy access to wire.
·
Entire unit is
compact and portable and will pass through a 16" (400mm) diameter manway.
Features And Benefits
The LN-25 semiautomatic wire feeder is ideal for
field or construction use. Since it is powered across the arc, no control cables
are needed! Simply connect the weld cable, attach the arc sensing clip, and
you’re ready to go. This portable MIG and flux-cored wire feeder comes in a
fully enclosed case to protect against damage on the job site. The LN-25
features a tool-less quick release mechanism for easy wire changing, and it
accepts 10-44 lbs. (4.5-19.9 kg) wire packages for plenty of welding
versatility.
·
For MIG and flux-cored arc welding processes using up to 44 lb. (19.9
kg) spools.
·
Designed for .023-1/16" (0.6-1.6mm) solid, .035-5/64" (0.9-2.0mm) cored
and .035-1/16" (0.9-1.6mm) aluminum wire sizes.
·
Selectable dial for setting low range, 50-350 ipm (1.3-8.9m/min) wire
feed speed or high range, 50-700 ipm (1.3-17.8m/min) wire feed speed.
·
Includes DC voltmeter, voltmeter polarity switch and 15 ft. (4.6m) arc
sensing lead and clip and 20" (508mm) weld power cable.
·
For use with Magnum® flux-cored and MIG guns.
·
Automatic overvoltage and motor overload shutdown protection.
·
Double-latched case features an insulated gun holder and easy access to
wire.
·
Entire unit is compact and portable and will pass through a 16" (400mm)
diameter manway.
·
Manufactured under a quality system certified to ISO 9001 requirements.
·
Three-year warranty on parts and labor.
Output
Input
Specifications
|
SOLID WIRE SIZE RANGE |
.023-1/16 in. (0.6-1.6 mm) |
|
CORED WIRE SIZE RANGE |
.035-5/64 in. (0.9-2.0 mm) |
|
WIRE SPEED RANGE IPM (M/MN) |
50-700 ipm (1.3-17.8 m/min) |
|
DIMENSIONS (H X W X D) IN |
14 in x 7.4 in x 21 in |
|
DIMENSIONS (H X W X D) MM |
(356 mm x 188 mm x 533 mm) |
|
NET WEIGHT |
40.000 lbs. (18.144 kg.) |
Included
·
Arc Sensing Lead & Clip,15 ft. (4.5m), Weld Power
Cable, 20" (508mm)
Accessories
|
CATEGORY |
PRODUCT NUMBER |
PRODUCT NAME |
|
General |
K484 |
Jumper Plug Kit |
|
General |
K1819-10 |
Control Cable |
|
General |
K1797-25 |
Control Extension Cable - 25 ft (7.6 m) |
|
General |
K1797-50 |
Control Extension Cable - 50 ft (15.2 m) |
|
General |
K363P |
Readi-Reel® Adapter 30 lb. |
|
General |
K435 |
Spindle Adapter for 14 lb. Coils |
|
General |
K468 |
Spindle Adapter for Small Spools |
Required Options
|
PRODUCT NUMBER |
PRODUCT NAME |
|
K852-70 |
Twist Mate™ Plug - For 1/0-2/0 (50-70mm2) Cable |
|
K852-95 |
Twist Mate™ Plug - For 2/0-3/0 (70-95mm2) Cable |
| Availability | In Stock |
|---|---|
| Manufacturer | LINCOLN ELECTRIC |
| Manufacturer Sku | K449 |
