MAKITA AF353 1-3/8" Pin Nailer, 23 Ga.

23 Gauge, 1-3/8" Pin Nailer

CONVENIENCE : 23 gauge pins create minimal nail holes for a faster and more professional looking finish

DURABILITY : Aluminum body, magazine, and cylinder for added strength

ERGONOMICS : Lightweight design, soft grip, and slim profile for easy operation

CONTROL : Nail lock-out mechanism protects tool and work surface from nail-less blank fires

INCLUDES : Pneumatic nailer oil, safety glasses, air fitting, no-mar tips (2), hex wrench, tool case

The Makita 23 Gauge Pin Nailer (model AF353) offers an array of features and powerful performance in a compact size. The AF353 has a side, drop-in loading magazine that accepts standard 23 ga. headless pins sized 5/8", 11/16", 3/4", 1", 1-3/16", and 1-3/8". The nail lock-out and red window alerts the user when to reload pins as the 2-finger trigger is used for controlled firing. With a compact size and weighing in at only 2 lbs., the AF353 was engineered for all-day professional use ideal for installing moulding, chair rail, tacking trim, glass retainers to doors, cross pinning dowels & joints, cabinets, paneling, glazed bead, craft work, picture frame assembly, window beading, rattan furniture, and a whole host of other woodworking applications. Additional convenience features include a reversible belt hook that allows the tool to remain close-by, a rear exhaust port that directs exhaust air away from the user and work surface, a built-in air duster that provides convenient air flow to clear your workspace, and 2 removable no-mar tips with sightlines for increased pinning accuracy.

Features

• Powerful motor drives standard headless pins sized 5/8", 11/16", 3/4", 1", 1-3/16" and 1-3/8"
• Aluminum body, magazine and cylinder for strength and durability; weighs only 2 lbs.
• Nail lock-out mechanism protects tool and work surface from pin-less blank fires (dry-fires)
• Side, drop-in loading magazine holds up to 130 nails for maximum efficiency
• Built-in air duster provides convenient air flow to clear work surface
• Double, 2-finger trigger for user convenience
• Rear exhaust port directs exhaust air away from operator and work surface
• Includes two removable no-mar tips with sightlines for increased pinning accuracy; convenient on tool storage
• Easy to clear nose for fast and easy nail extraction should a jam occur
• Narrow nose design allows easy nailing access to tight areas and angles
• Magazine self adjusts to the proper 5/8", 3/4", 1", 1-3/16" or 1-3/8" fastener length when loaded
• Reversible belt hook allows the tool to remain close
• Housing bumpers protect tool and work surface
• Integrated rubber soft grip for operator comfort
• Ideal for installing moulding, chair rail, tacking trim, glass retainers to doors, cross pinning dowels & joints, cabinets, paneling, glazed bead, craft work, picture frame assembly, window beading, rattan furniture, and a wide variety of other woodworking applications
• Minimum recommended air delivery of .9 SCFM @ 90PSI
• 3-year limited warranty

Includes

(1) Pneumatic Nailer Oil (181434-7)

(1) Safety Glasses

(2) No-Mar Tip

(1) Air Fitting

(1) Hex Wrench

(1) Tool Case
