MAKITA LS0815F 8-1/2” Slide Compound Miter Saw, L.E.D. Light
8-1/2” Slide Compound Miter Saw
Features
Compact and Lightweight Design for Job Site Portability
·
Powerful 10.5 AMP direct drive motor requires
less maintenance and delivers 5,000 RPM
·
Miters 0°- 50° left and 0°- 60° right, with
positive stops at 0°, 15°, 22.5°, 31.6°, 45° and 50° (left and right) plus 60°
(right)
·
Compact and lightweight (31.1 lbs.) for job site
portability
·
Cuts up to 12” at 90° and 8-1/2” at 45°
·
Linear ball bearing system engineered to deliver
"dead-on" accurate cuts
·
Dual rear handle bevel lock is easily accessible
and adjusts 0°- 48° (left) and 0°- 5° (right) with positive stops at 0° and 45°
(left)
·
Soft start feature for smooth start-ups
·
Built-in L.E.D. light illuminates the line of cut
for increased accuracy
·
Exclusive 2-1/2" tall fence system for increased
vertical cutting capacity
·
Ergonomic rubberized D-handle design for better
fit and added comfort
·
Large precision machined aluminum base supports
material for more efficient cutting
·
Electric brake for maximum productivity
·
See-through blade guard system for greater
visibility of the line of cut
·
Oversized trigger switch for better fit, added
comfort and easier operation
·
Connects directly to Makita Xtract Vac® (VC4710)
for a cleaner work area
·
Includes extension wings for supporting long work
pieces
·
Ideal for baseboard and crown molding
installation, finish carpenters, cabinet and furniture makers, wood floor
installers, deck builders, general construction and more
Specifications
INCLUDES:
·
(1) 8-1/2" 48T Miter Saw Blade (JM23570003)
·
Triangle Rule for Miter Saws (JM27000328)
·
Vertical Vise, LS0815F (JM23510009)
·
Dust Bag Assembly, LS0815F (JM23510010)
·
Box Wrench, LS0815F (782230-2)
|
Blade Diameter |
8-1/2" |
|
Arbor |
5/8" |
|
Max. Cutting Capacity (miter 90°)
|
2-9/16" x 12" |
|
Max. Cutting Capacity (miter 45°, L/R)
|
2" x 8-1/2" |
|
Max. Cutting Capacity |
12" |
|
No Load Speed |
5,000 RPM |
|
AMPS |
10.5 |
|
Dimensions (LxWxH) |
29-3/4" x 17-3/4" x 19-1/4" |
|
Net Weight |
31.1 lbs. |
|
Shipping Weight |
41.8 lbs. |
| Availability | In Stock |
|---|---|
| Manufacturer | MAKITA |
| Manufacturer Sku | LS0815F |
