MAKITA RH01R1 12V max CXT™ 5/8" Rotary Hammer Kit, SDS-PLUS(2.0Ah), Lithium-Ion Brushless Cordless

$306.77
In stock
SKU
2535394

12V max CXT™ Lithium-Ion Brushless Cordless 5/8" Rotary Hammer Kit, accepts SDS-PLUS bits (2.0Ah)

INNOVATION : Ideal for working in tight spaces and overhead applications

PERFORMANCE : Brushless motor delivers 0-680 RPM, 0-4,800 BPM and 1.1 joules of impact energy for faster drilling

COMFORT : Vibration absorbing handle moves independently of the hammer for increased operator comfort

VERSATILITY : 2-Mode operation for "Rotation Only" or "Hammering with Rotation" for multiple applications

INCLUDES : Includes - (2) 12V max CXT™ Lithium-Ion batteries, charger, handle, depth gauge and tool case

The 12V CXT™ Lithium-Ion Brushless 5/8” Rotary Hammer Kit (RH01R1) is a compact concrete drilling solution powered by an efficient Makita BL™ Brushless Motor for up to 50% longer run time, increased power and speed, and longer tool life. The RH01Z delivers 0-680 RPM, 4,800 BPM, and 1.1 Joules of impact energy. Ease-of-use and efficiency features include 2-mode operation (rotation only, hammering with rotation), a variable speed trigger, and a vibration-absorbing handle that moves independently of the motor and hammer mechanism for increased operator comfort.

For longer run time, 12V max CXT™ cordless tools are also compatible with 12V max CXT™ Lithium-Ion 4.0Ah batteries (BL1041B, sold separately). 12V max CXT™ Lithium-Ion batteries are engineered with a Battery Protection Circuit that protects against overloading, over-discharging and over-heating. It’s part of the expanding 12V max CXT™ series, combining performance with superior ergonomics in a compact size.

Features

  • Brushless motor delivers 0-680 RPM, 0-4,800 BPM and.81ft.lbs./1.1 joules of impact energy for faster drilling
  • Compact and Ergonomic design at only 9-7/8"
  • Weighs only 4.0 lbs. with battery for reduced operator fatigue
  • Vibration absorbing handle moves independently of the motor and hammer mechanism for increased operator comfort
  • The electronically-controlled BL™ Brushless Motor efficiently uses energy to match torque and RPM to the changing demands of the application
  • Efficient BL™ Brushless motor is electronically controlled to optimize battery energy use for up to 50% longer run time per charge
  • The BL™ Brushless Motor eliminates carbon brushes, enabling the BL Motor to run cooler and more efficiently for longer life
  • For dust management use Dust Extraction Cup (198362-9) with Side Handle Spacer (122810-6), Side Handle Base (450120-4) and Bolt (921919-9)
  • 2-Mode operation for "Rotation Only" or "Hammering with Rotation"
  • Variable speed trigger enables user to match the speed to application for greater versatility
  • Built-in L.E.D. light illuminates the work area
  • One-touch sliding chuck for easy bit changes
  • Battery Protection Circuit protects against overloading, over-discharging and over-heating
  • 12V max CXT™ Lithium-Ion 2.0Ah battery BL1021B, features an integrated L.E.D. battery charge level indicator
  • Part of the expanding 12V max CXT™ series, combining performance with superior ergonomics in a compact size
  • Not compatible with 12V max pod-style tools, batteries and chargers
  • 3-year limited warranty on tool, battery and charger
  • Only use genuine Makita batteries and chargers

Specifications

Max. Capacity (concrete drilling)

 5/8"

Optimum Range (concrete drilling)

 5/32" - 3/8"

Impact Energy (Joules)

 1.1 J

Impact Energy (ft.lbs.)

 .81

Vibration (m/s²)

 7.5

No Load Speed (variable speed)

 0 - 680 RPM

Blows Per Minute (variable speed)

 0 - 4,800 BPM

Battery

 12V max CXT™ Lithium-Ion

Overall Length

 9-7/8"

Net Weight (with battery)

 4 lbs.

Bit Type

 Accepts SDS-PLUS

Power Type

 Cordless

Shipping Weight

 9.65 lbs.

UPC Code

 088381-838511



Includes

(2) 12V max CXT™ Lithium-Ion 2.0Ah Battery (BL1021B)

(1) 12V max CXT™ Lithium-Ion Charger (DC10WD)

(1) Side Handle (144218-4)

(1) Interlocking Case, Medium (197211-7)

More Information
Availability In Stock
Manufacturer MAKITA
Manufacturer Sku RH01R1
