MILWAUKEE 2236-20NST CLAMP METER HVAC/R NIST

The Milwaukee Clamp Meter for HVAC/R (NIST) is a heavy duty True-RMS electrical current tester for professional residential, commercial, and industrial applications. The perfect tool for the professional HVAC/R technician, the 2236-20 clamp meter provides a wide 1.3” jaw opening to easily handle large conductors, a thin jaw profile for access to tight spaces and a high contrast white-on-black display for clearer readings. In addition, the Milwaukee Clamp Meter for HVAC/R was designed with embedded non-contact voltage detection and an LED work light to increase end user productivity. A NIST Certificate of Calibration with Data is also included, needed by many organizations as proof of calibration with the date when NIST Calibration was performed. Covered by Milwaukee 5-Year Warranty.

Includes

·         2236-20 Clamp

·         Test Leads

·         Dual Banana Thermocouple

·         (2) AA Batteries

·         Manual

·         NIST Certificate of Calibration with Data

Features

·         Measures up to 600 amps AC, Large 1.30” jaw opening

·         Thin Jaw Profile for easier wire measurement in panels or in bundles

·         Wide Voltage range to 600 AC/DC volts

·         True-RMS for accurate measurement in all applications

·         Built-In Voltage Detector and LED Work Light

·         Thermocouple (dual banana) input for contact temperature measurement

·         600 uA DC for Flame Rectification

·         High Contrast, White on Black Display with Backlight for easy reading

·         Rugged over-molding increases durability and user grip

Specifications
