MILWAUKEE 4096 DRILL DMD 450/900 20A CL
$795.95
In stock
SKU
853244
Diamond coring motors are used with Vac-U-Rig® and Dymorig
diamond core rigs to drill holes into reinforced concrete. This 20 amp model
features 4.8 peak horsepower with a 450 rpm or 900 rpm operating speed. The 4096
has a clutch to protect gears and motor against overload. This unit will handle
core bits from 2 in. to 10 in. in diameter.
Includes
·
Built-In Water Swivel
·
Water Hose Adapter
·
Water Control Valve
·
Open End Wrench
Features
·
Two speeds: 450 and 900 rpm
·
20 amp motor
·
Shear pin protection protects gears and motor
·
Built-in water swivel
Specifications
|
Voltage |
120 AC |
|
Amps |
20.0 |
|
No Load RPM |
Low=450/High=900 |
|
Motor Protection |
Clutch |
|
Spindle |
1-1/4"-7 |
|
Plug Type |
L5-20P |
|
Max Capacity in Concrete |
10" |
|
Max HP |
4.8 |
|
Sugg Dia In Med Aggregate |
6 in.-10 in. / 2 in.-6 in. |
|
Tool Weight |
24.0 lbs. |
|
Shipping Weight |
31.0 lbs. |
| Availability | In Stock |
|---|---|
| Manufacturer | MILWAUKEE |
| Manufacturer Sku | 4096 |
