NITTO KOHKI WA-5000 Semi-Automatic Drill 115V - 2" x 3" hole capacity
$1,864.08
In stock
SKU
1034698
WA-5000 Nitto Kohki
Simi-Automatic Mag-Based Drill
Standard Features
-
2" x 3 " hole drilling capacity
-
automatic feed with slow start
mechanism
-
Step feed feature optimizes cutter
penetration
-
Load detection system monitors and
regulates motor speed and cutting feed
-
Powerful 1150 watt double
insulated motor
-
Overload stop detection system
helps prevent motor and cutter damage
-
Load detection system monitors and
regulates motor speed and cutting feed
-
Sealed arbor system with through
spindle coolant
-
Built-in motion detection system
-
One touch arbor system
-
No tools required for cutter
installation and removal
-
Accepts carbide tipped and High
Speed annular cutters
-
Precision machined die cast
aluminum mainframe, motor slide and arbor support bracket
-
One year limited warranty
Specifications
|
Power Source |
110-120V AC |
|
Rated Power Consumption |
1,150 W |
|
Rated Current |
10.8 A |
|
No Load Speed |
350/650 RPM |
|
Magnet Power Consumption |
75 W |
|
Hole Diameter |
2" Max |
|
Depth of Cut |
3" Max |
|
Magnet Holding Power |
2,200 lbs |
|
Magnet Dimensions |
4" x 8" |
|
Weight |
51 lbs |
Standard Accessories
-
2" Pilot pin
-
Hex Keys
-
8 x 10 mm combination wrench
-
Chip guard assembly
-
Motor side handle
-
Sample cutting fluid
-
Safety chain
-
Carrying case
| Availability | In Stock |
|---|---|
| Manufacturer | NITTO KOHKI |
| Manufacturer Sku | WA-5000 |
