NORTON 66252801864 6 x 1/8 x 7/8 Type 27 Depressed Center Wheels - Good Norton Gemini Disc
$3.77
In stock
SKU
1908353
DEPRESSED CENTER WHEELS
Depressed center wheels may also be referred to as raised
hub wheels or by their shape designation of “type”, with type 27 being the most
popular. The depressed center design allows the flange/lock nut to recess within
the wheel so that it can be used for various grinding and cutting applications.
Depressed center wheels are designed to handle the most severe right angle
grinding applications from heavy stock removal to rough blending. More recently,
depressed center wheels have been designed to increase the utility of the tool
for cut-off applications. While large right angle grinders (7" & 9") have been
around for many years, small or mini grinders that handle 4", 4-1/2" and 5"
wheels have made this machine, and wheel category, the most popular in power
tools.
|
Applications: |
Grinding, stock removal, edge chamfering, beveling, weld blending, and
cutting-off |
|
Size range: |
2" – 9" |
|
Thickness range: |
.040 (1/32) – .250 (1/4") |
|
Grit range: |
24 – 46 grits for stock removal; 60, 80, 120 grits for blending and
finishing |
|
Abrasive grain: |
Ceramic alumina, zirconia alumina, aluminum oxide, silicon carbide |
|
Mounting options: |
Plain hole (5/8" and 7/8") and discard mount (5/8"-11 and 3/8"-24) |
|
Shape: |
Type 27, type 28, type 29 |
Note: For more information on DEPRESSED CENTER WHEELS
see detailed Images.
Features
|
TIER: |
BEST |
BETTER |
GOOD |
GOOD |
|
TRADENAME: |
NORTON NORZON PLUS |
NORTON BLUEFIRE |
NORTON GEMINI |
NORTON METAL |
|
SHAPE: |
TYPE 27 AND TYPE 28 |
TYPE 27 AND TYPE 28 |
TYPE 27 AND TYPE 28 |
TYPE 27 |
|
ABRASIVE: |
CERAMIC ALUMINA/ZIRCONIA ALUMINA |
ZIRCONIA ALUMINA/ALUMINUM OXIDE |
ALUMINUM OXIDE |
ALUMINUM OXIDE |
|
MATERIAL: |
STAINLESS |
STAINLESS |
STAINLESS |
STAINLESS |
|
STEEL/METAL |
STEEL/METAL |
STEEL/METAL |
STEEL/METAL |
Specifications
3/32", 1/16", 1/8",
5/32" – cutting / notching / light grinding – type 27
|
Size (d x t x h) |
Max. Rpm |
Std. Pkg. |
Part no |
Part no |
Part no |
Part no |
|
3
x 1/8 x 3/8 |
18,000 |
25 |
66252842177 |
--- |
--- |
--- |
|
4
x 1/8 x 3/8 |
15,280 |
25 |
66252842004 |
66252843178 |
66252843178 |
--- |
|
4
x 1/8 x 5/8 |
15,280 |
25 |
66252842005 |
66252843176 |
66252842017 |
66252842014 |
|
4-1/2 x 3/32 x 5/8-11 |
13,580 |
25 |
--- |
--- |
66252841903 |
--- |
|
-- |
--- |
10 |
--- |
--- |
66252842027
INOX |
--- |
|
4-1/2 x 3/32 x 7/8 |
13,580 |
25 |
--- |
--- |
66252841940 |
--- |
|
--- |
--- |
25 |
--- |
--- |
66252842028 INOX |
--- |
|
--- |
--- |
25 |
--- |
--- |
66252843582
1-2-3 |
--- |
|
4-1/2 x 1/8 x 5/8-11 |
13,580 |
10 |
66252843323 |
66252843211 |
66252843590 |
--- |
|
--- |
--- |
10 |
--- |
66252843191
FC |
66252843609 |
--- |
|
--- |
--- |
10‡ |
--- |
--- |
66252842166 2-pk |
--- |
|
4-1/2 x 1/8 x 7/8 |
13,580 |
25 |
66252843324 |
66252843212 |
66252843591 |
66252843611 |
|
--- |
--- |
25 |
--- |
66252843190
FC |
--- |
--- |
|
--- |
--- |
10‡ |
-- |
--- |
66252842167 2-pk |
--- |
|
5
x 3/32 x 5/8-11 |
12,225 |
25 |
--- |
--- |
66252841904 |
--- |
|
5
x 3/32 x 7/8 |
12,225 |
25 |
--- |
--- |
66252842037 INOX |
--- |
|
--- |
--- |
--- |
--- |
--- |
66252843587
LL |
--- |
|
--- |
--- |
--- |
--- |
--- |
66252843583 1-2-3 |
--- |
|
5
x 1/8 x 5/8-11 |
12,225 |
10 |
66252843330 |
66252843215 |
--- |
--- |
|
--- |
--- |
10 |
--- |
66252843195
FC |
--- |
66252843615 |
|
5
x 1/8 x 7/8 |
12,225 |
25 |
66252843331 |
66252843216 |
66252843596 |
--- |
|
--- |
--- |
25 |
--- |
66252843194
FC |
--- |
66252843616 |
|
5
x 5/32 x 7/8 |
13,580 |
25 |
--- |
--- |
66252842038 |
--- |
|
6
x 3/32 x 5/8-11 |
10,185 |
10 |
---- |
--- |
66252841905 |
--- |
|
6
x 3/32 x 7/8 |
10,185 |
10 |
--- |
--- |
66252841906 |
--- |
|
--- |
--- |
--- |
--- |
--- |
66252832487
INOX |
--- |
|
6
x 1/8 x 5/8-11 |
10,185 |
10 |
66252841891 |
66252843199
FC |
66252833965 |
--- |
|
6
x 1/8 x 7/8 |
10,185 |
20 |
--- |
66252843202 |
66252801864 |
--- |
|
--- |
--- |
20 |
--- |
66252843198
FC |
--- |
--- |
|
6
x 5/32 x 5/8-11 |
10,185 |
10 |
--- |
--- |
66252841193 |
--- |
|
6
x 5/32 x 7/8 |
10,185 |
20 |
--- |
--- |
66252835580 |
--- |
|
7
x 1/16 x 7/8 |
8,600 |
20 |
--- |
--- |
66252912626 |
--- |
|
7
x 3/32 x 5/8-11 |
8,600 |
10 |
--- |
--- |
66252841907 |
--- |
|
7
x 3/32 x 7/8 |
8,600 |
20 |
---- |
--- |
66252841908 |
--- |
|
7
x 3/32 x 7/8 |
8,600 |
20 |
--- |
--- |
66252914638
INOX |
--- |
|
7
x 1/8 x 5/8-11 |
8,600 |
10 |
66252938855 |
66252843233 |
66252939259 |
07660702678 |
|
--- |
--- |
10 |
--- |
66252843183
FC |
--- |
--- |
|
7
x 1/8 x 7/8 |
8,600 |
20 |
66252938854 |
66252843234 |
66252939207 |
--- |
|
--- |
--- |
20 |
---- |
66252843182
FC |
--- |
--- |
|
--- |
--- |
25* |
--- |
--- |
--- |
07660775956 5-pk |
|
7
x 5/32 x 7/8 |
8,600 |
20 |
--- |
---- |
66252835581 |
--- |
|
9
x 1/8 x 5/8-11 6,600 |
10 |
66253048897 |
66252843244 |
66253048983 |
--- |
|
|
--- |
--- |
10 |
--- |
66252843187
FC |
--- |
--- |
|
9
x 1/16 x 5/8-11 |
6,600 |
10 |
--- |
--- |
66253019115 |
--- |
|
9
x 1/8 x 7/8 6,600 |
20 |
66253048896 |
66252843245 |
66253048994 |
--- |
|
|
---- |
--- |
20 |
--- |
66252843186
FC |
--- |
--- |
* 5-wheel job packs; wheels are packed 5 wheels/pack, with
5 job packs/carton. Order per each wheel in standard package Quantities of 25.
Order in multiples of 25. ‡ 2-wheel small packs (vendible/peggable); wheels are
packed 2 wheels/pack, with 5 packs/carton. Order per each wheel in standard
package Quantities of 10.
FC = fast cut
HD = heavy duty
INOX = contaminant free
LL
= long life
1-2-3 = cutting/notching/grinding
BLANK = all purpose
¦ =
aluminum
¦ =
foundry
¦
= masonry
¦
= stainless
¦
= steel / metal
| Availability | In Stock |
|---|---|
| Manufacturer | NORTON |
| Manufacturer Sku | 66252801864 |
