POWERMATIC 1280101C PM2700 Shaper, 5HP 1PH 230V, DRO, Casters -LTL
$4,899.99
Out of stock
SKU
1175710
This new PM2700 Shaper offers more features to you than any
other shaper in the same class. The extra large 30" x 40" precision ground cast
iron table includes a heavy duty miter gauge with an aluminum extruded support.
The built-in, omni-directional caster system (patent pending) is retractable
into the base. A quick-release lever allows fast speed and belt changes. The
extruded aluminum fence has several T-slots so you can mount a wood face to
create a no-clearance surface around any shaper or router bit. The fence also
gives you the ability to quickly move the fence close to its final position,
lock it in and then use the precision micro adjustments on each side of the
cutter to dial in exactly the position you need. Adding to the precision of this
machine is a digital readout for the spindle height. This allows making
adjustments to within .001" in the spindle height, which is critical when
aligning rail and stile cutters for those raised panel doors.
Product Features
·
Integrated caster system built into the cast iron
base for instant shop mobility
·
Spindle height digital readout for making fine
incremental adjustments on multiple passes
·
Heavy duty 30" x 40" precision ground tabletop
for smooth stock feeding
·
Convenient quick lock belt tensioning for easy
speed adjustment
·
Industrial fence system with fine adjust dials
for more precise positioning
·
5HP totally enclosed motor offers plenty of power
·
Two spindle speeds (reversible) for a variety of
work
·
Superior clear cutter guard promotes safety,
allows observation of the entire cut
·
Table predrilled and tapped for feeder mounting
in two locations
·
Fence has dual featherboards for work holding
·
Dual 4" ports for attachment to dust collection
system
·
Standard Equipment:
·
3/4" and 1-1/4" interchangeable spindle collets
·
Spindle height digital readout
·
Featherboard hold downs
·
Deluxe miter gauge
·
Integrated caster system
Specifications
|
Part Number |
1280101C |
|
Spindle Speed |
7500 and 10,000 RPM |
|
Reversable |
Yes |
|
Spindle Diameter |
3/4 and 1 1/4 " |
|
Spindle Size Under Nut |
3/4 (3 3/4) and 1 1/4 (6) "
|
|
Spindle Travel |
4 |
|
Tilting Spindle |
n.a. |
|
Table Size |
40 x 30 " |
|
Table Height From Floor |
35.5 " |
|
Table Opening Diameter |
7 3/8 " |
|
Table Insert Opening Diameter |
2 35/64, 4 5/32 and 5 3/4 "
|
|
Fence Size (L x H) |
18 3/4 x 4 7/8 " |
|
Fence Travel (Major and Minor) |
n.a. |
|
Slide Table Size (L x W) |
n.a. |
|
Table Travel |
n.a. |
|
Table Inserts |
2 35/64, 4 5/32 and 5 3/4 "
|
|
Router Bit Collet Diameter |
1/4 and 1/2 " (optional) |
|
Dust Port Outside Diameter |
4 " (dual ports) |
|
Dust Collection Minimum CFM Required |
600 cu.ft/min |
|
Electrical Controls - Magnetic Starter |
Yes |
|
Digital Readouts |
spindle height |
|
Motor Power |
5 HP |
|
Motor Voltage |
230 V |
|
Motor Phase |
1 Ph |
|
Web Description |
PM2700 Shaper, 5HP 1PH 230V
|
|
Model Number |
PM2700 |
|
Brand |
Powermatic |
|
Overall Dimensions |
40x37x45 |
|
Height |
45 inch |
|
Width |
37 inch |
|
Length |
40 inch |
|
Net Weight |
769 pound |
| Availability | Out of Stock |
|---|---|
| Manufacturer | POWERMATIC |
| Manufacturer Sku | 1280101C |
