POWERMATIC 1792072K PM1900TX-CK1 Dust Collector, 3HP 1PH 230V, 2-Micron Canister Kit -LTL

$1,899.99
Out of stock
SKU
1522042

The PM1900 Dust Collector is strong enough to use with planers, wide belt sanders, table saws and most other woodworking machines. The exclusive TurboCone™ improves chip separation to prevent clogging of the filter, and increases packing efficiency of the collector bags. The canister filter offers superior filtering surface area over standard bags, and captures 98% of 2-micron particles. The all-metal duct improves rigidity and air flow. The clear collector bags are large capacity, which means less down-time changing them. Four swivel casters and conveniently located handles allow for easy mobility.

Product features

·         TurboCone improves chip separation and collector bag packing efficiency

·         The cone eliminates premature filter clogging for sustained performance

·         All-metal duct construction for rigidity and improved air flow

·         30-micron filter bags for improved capture of fine dust particles

·         The large impeller is powered by a 3HP motor for peak performance

·         Triple 4” dust ports allow for several hoses to be attached at the same time

·         Cloth collection bags with view window use a snap ring for rapid installation/removal

·         10 cubic feet collection bag capacity reduces number of bag changes.

·         Tall filter bags require less cleaning due to the larger surface area

·         Four swivel casters for easy maneuverability

Specifications

Part Number

1792072K

Trademark

TurboCone

Remote Control

Yes

Sound Rating

86 - 92 dB

1-Hose Connection Diameter

8 "

2-Hoses Connection Diameter

4 "

3-Hoses Connection Diameter

4 "

Bag Diameter

20 "

Filter Bag/Canister Length

26 "

Collection Bag Capacity

10 cubic foot

Collection Bag Length

30 "

Air Flow @ 4"

236 cu.ft/min

Air Flow @ 8"

1,782 cu.ft/min

Static Pressure

11.31 inch of water

Particle Size (Micron)

98% of 2 micron particles: 86% of 1 micron particles

Velocity @ 4"

5,200 foot per minute

Air Inlet

(1) at 8" or (3) at 4"

Impeller Diameter

14 "

Impeller Fins

7

Impeller Material

steel

Separator Tank Diameter

20 "

Separator Tank Height

10 "

Motor Power

3 HP

Motor Phase

1 Ph

Motor Voltage

230 V

Prewired Voltage

230 V

Motor Current

15 A

Web Description

PM1900TX-CK1 Dust Collector, 3HP 1PH 230V, 2-Micron Canister Kit

Model Number

PM1900TX-CK1

Brand

Powermatic

Overall Dimensions

46 x 23 x 45 (shipped), 61 x 30 x 72 (assembled)

Height

45 inch

Width

23 inch

Length

46 inch

Net Weight

268 pound



More Information
Availability Out of Stock
Manufacturer POWERMATIC
Manufacturer Sku 1792072K
